Avonic CM63-IP User Manual

Full hd video ip camera with poe
Hide thumbs Also See for CM63-IP:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Version 2.5
Update notes:
RC settings
•
SDI definition
•
Avonic
CM63-IP
Full HD Video IP Camera with PoE
Join Avonic
linkedin.com/company/avonic
twitter.com/avonic1
facebook.com/avonic

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM63-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Avonic CM63-IP

Summary of Contents for Avonic CM63-IP

  • Page 1 Avonic CM63-IP Full HD Video IP Camera with PoE User Manual Version 2.5 Join Avonic Update notes: linkedin.com/company/avonic RC settings twitter.com/avonic1 • SDI definition facebook.com/avonic •...

  • Page 2: Table Of Contents

    RS485 network connection diagram ..................................13 Operation ....................14 OSD Menu ..................................................14 1. MENU ................................................16 2. EXPOSURE ............................................... 16 3. COLOR ............................................... 17 4. IMAGE ................................................. 18 5. P/T/Z................................................19 6. NOISE REDUCTION ........................................20 7. SETUP ................................................. 20 www.avonic.eu...
  • Page 3 Appendix A ..................36 VISCA Camera Return Command List ................................36 VISCA Camera Control Command List ................................37 VISCA Query Command List ........................................ 41 Pelco-D Protocol Command List ....................................46 Pelco-P Protocol Command List ....................................46 VISCA over IP commands ........................................47 www.avonic.eu...
  • Page 4 Appendix B Quick Start ..............55 Appendix C Dimensions ............... 56 www.avonic.eu...

  • Page 5: Introduction

    Introduction Congratulations Thank you for purchasing the Avonic CM63-IP HD PTZ Camera. Before beginning to operate this device, please read the manual in order to make sure the best performance is obtained. Save this manual for future reference. Safety Notes Installation and servicing should only be done by Qualified Service Personnel and •...

  • Page 6: Accessories

    Accessories Wall mount in White and Black Avonic SKU : CM-WMW : CM-WMB Ceiling mount in White and Black Avonic SKU : CM-CMW : CM-CMB www.avonic.eu...

  • Page 7: Product Overview

    The cameras are equipped with a Panasonic CMOS sensor combined with a glass high-quality glass lens with 30x optical zoom. Control these cameras over RS232/485 with the Avonic CM-CON100 PTZ controller or any third party controller that supports VISCA, Pelco-P/D protocols.

  • Page 8: Main Unit

    Audio LINE IN Interface CVBS Interface System select switch 4. RS485 interface 5. RS232 IN interface 6. RS232 OUT interface Network Interface 8. HDMI Interface 9. 3G-SDI Interface (SMPTE 424M) 10. USB2.0 (update only) DC 12V jack 12. Power switch www.avonic.eu...

  • Page 9: Ir Remote Controller

    MANUAL button, and adjust it with [Far] (Focus on far object) and [NEAR] (Focus on near object) 10. Camera IR channel Select Buttons Press the button corresponding to the camera you want to operate with the remote controller. # Button Used with other buttons 12. Set Camera IR Address Buttons www.avonic.eu...

  • Page 10: Remote Control Shortcuts

    Remote Control IR channel Settings [*]+[＃]+[F1]: The camera is set to IR channel 1. [*]+[＃]+[F2]: The camera is set to IR channel 2. [*]+[＃]+[F3]: The camera is set to IR channel 3. [*]+[＃]+[F4]: The camera is set to IR channel 4. www.avonic.eu...

  • Page 11: Installation

    Installation Connection Diagram System Select Switch Setting of the system select switch. The option of video format: VIDEO SYSTEM 1080p60 720p30 1080p50 720p25 1080i60 1080i50 720p60 720p50 576i www.avonic.eu...

  • Page 12: Power Adapter

    RS232-IN of the first camera in the serial circuit. The RS232-OUT of the first camera is connected to the RS232-IN of the second camera and so on. In the OSD menu under Communication Setup, the Protocol is Auto / VISCA, and Net mode is www.avonic.eu...

  • Page 13: Rs485 Network Connection Diagram

    The maximum length of the bus is 1200m. The maximum distance from the bus to the camera or controller is 5 meters. The cameras are connected with the 2-pin Phoenix connector. In the OSD menu under Communication Setup, Net mode is set to Paral. www.avonic.eu...

  • Page 14: Operation

    Operation OSD Menu The OSD menu can be accessed by the Remote Control or an Avonic PTZ controller. In the following pages, the navigating is described for using the IR Remote Control. Menu Tree www.avonic.eu...
  • Page 15 www.avonic.eu...

  • Page 16: Menu

    Setup Communication Setup Restore Default [Home] Enter [Menu] Exit 2. EXPOSURE EXPOSURE Mode Auto ExpCompMode On ExpComp Backlight Shutter Iris Bright Gain Limit Meter Average Anti-Flicker 50Hz Meter Average Gain Select Item Change Value [Menu] Back Mode Exposure mode. www.avonic.eu...

  • Page 17: Color

    1/1000, 1/1500, 1/2000, 1/3000, 1/4000, 1/6000, 1/10000 (Effective only in Manual, SAE mode) Gain Optional items: 0 ~ 7 (Effective only in Manual) 3. COLOR COLOR WB Mode Auto Color Temp RG Tuning BG Tuning Saturation AWB Sens Select Item Change Value [Menu] Back WB-Mode White balance mode. www.avonic.eu...

  • Page 18: Image

    [Menu] Back Luminance Brightness adjustment. Optional items: 0 ~ 14 Contrast Contrast adjustment Optional items: 0 ~ 14 Sharpness Sharpness adjustment. Optional items: Auto, 0 ~ 15 Flip-H Image flipped horizontally. Optional items: On, Off. Flip-V Image Flip Vertical. www.avonic.eu...

  • Page 19: P/T/Z

    Automatic focusing sensitivity options, Optional items: Low, Normal, High L/R Set Optional items: STD, REV Display info On, Off Image Freeze Optional items: On, Off Digital Zoom On, Off Call Preset Speed 1 ~ 24 Fast Zoom Optional items: On, Off www.avonic.eu...

  • Page 20: Noise Reduction

    DVI Mode Lens Type1 Auto scan shoot Off Select Item Change Value [Menu] Back Language menu language, Optional items: EN, Chinese, Russian DVI Mode Optional items: DVI, HDMI Lens Optional Items: Type1, Type2 Auto Scan Shoot Optional Items: On, Off www.avonic.eu...

  • Page 21: Communication Setup

    Optional items: 0 ~ 254 P_P_Address PELCO-P protocol Optional items: 0 ~ 31 Baudrate Serial port baud rate. Optional items: 2400, 4800, 9600, 38400 9. RESTORE DEFAULT RESTORE DEFAULT Restore? Change Value [Home] OK [Menu] Back Restore Confirm restore factory settings. www.avonic.eu...

  • Page 22: Serial Communication Control

    (Note: If the position preset 0 has been stored, the position preset 0 will be called up after initialization) Then the users can control the camera with commands in the command list. Command List See Appendix A www.avonic.eu...

  • Page 23: Network Function

    To find the camera’s IP settings, press * and # and 4 on remote controller one by one. The IP address will be shown on the screen. Change IP address: On web control page, find "Network"--->Change IP---->Click "Apply"----> Restart camera www.avonic.eu...

  • Page 24: Visit/Access Ip Camera

    Visit/Access IP Camera Input http://192.168.100.88 to web browser, a login window pop up, input login name: admin password: admin A window like the following will appear: www.avonic.eu...

  • Page 25: Tcp/Udp Control

    TCP/UDP Control The Avonic IP camera is implemented with a TCP server inside. The default TCP port number is 5678. This number can be changed in the WebGUI in the Network Menu. Once the connection between client and server is set up, the client will be able to send VISCA PTZ commands to the server.
  • Page 26 : When PTZ turn to expected position, can set up a number of preset that user want. click "Set" button, when PTZ turn to other position, click "Call" button, PTZ turn back to preset position. Language selection Available options are : Chinese/English/Russian www.avonic.eu...

  • Page 27: Video

    : Restrain the fluctuation magnitude of variable rate, grade 1 ~ 6 Slice Split Enable : On, Off Split Mode Slice Size Setting hints: The bigger resolution is, the clearer the image will be, more network bandwidth will be taken. www.avonic.eu...

  • Page 28: Image Setup

    Contrast : Contrast 0~14, slider control, Default 6. Sharpness : Sharpness 0~15, slider control, Default 1. : Hue 0~14, slider control, Default 7. Flip & Mirror : Tick Flip; image upside down, tick mirror; image mirrored. Default not tick. www.avonic.eu...

  • Page 29: Audio Setup

    : 96k, 128k, 256k Input Type : line in only Input Vol. L : The volume of the left channel Input Vol. R : The volume of the right channel ADTS Options : On, Off System Setting Work Mode : RTSP www.avonic.eu...
  • Page 30 Reboot : Click the "Reboot" button, system restart. User and password : The user can modify the password (letters and numbers only) Guest and password: The user can modify the password for a guest (letters and numbers only) www.avonic.eu...

  • Page 31: Network Setting

    Network Setting www.avonic.eu...
  • Page 32 Setting IP camera RTSP protocol of "On", "Off". ONVIF Settings Setting the ONVIF protocol and ONVIF authorization "On", "Off". Multicast Settings Setting multicast "On", "Off", and multicast address (default address 224.1.2.3) and port (default 6688) SDK Settings For System Developers only NTP Settings www.avonic.eu...

  • Page 33: Rtsp Stream Media Player

    : 554; 1024-65535 (default 554) PTZ Port range : 1024-65535 (default 5678) Multicast Port range : 1024-65535 (default 6688) Device Information Show the current device information, as shown below. If you need the camera upgrade program, please contact Avonic. www.avonic.eu...

  • Page 34: Maintenance

    1. Access to the network with PC can test whether network works, in this way to get rid of cable failure, network failure caused by PC virus until the PC can be Ping. 2. Disconnect IP Camera with network, IP Camera and PC are connected, according to the www.avonic.eu...

  • Page 35: Control

    2. Check control cable is connected correctly. Contact For any questions or suggestions, contact the reseller or the local distributor of Avonic. Find the local distributor on the website of Avonic. For the recent manual or datasheet, look at the Avonic website.

  • Page 36: Visca Camera Return Command List

    Return when the (y: Socket No.) command has been executed. Command Function Command Package Note Error Syntax Error z0 60 02 FF Returned when the Messages command format is different or when a command with illegal command parameters is sent. www.avonic.eu...

  • Page 37: Visca Camera Control Command List

    8x 01 04 08 2p FF p = 0(low) - 7(high) Near(Variable) 8x 01 04 08 3p FF Direct 8x 01 04 48 0p 0q 0r 0s pqrs: Focus Position Auto Focus 8x 01 04 38 02 FF AF On/Off www.avonic.eu...
  • Page 38 8x 01 04 4B 00 00 0p 0q pq: Iris Position CAM_Gain Reset 8x 01 04 0C 00 FF Gain Setting 8x 01 04 0C 02 FF Down 8x 01 04 0C 03 FF Direct 8x 01 04 0C 00 00 0p 0q pq: Gain Position www.avonic.eu...
  • Page 39 Image Flip Horizontal On/Off 8x 01 04 61 03 FF CAM_PictureFlip 8x 01 04 66 02 FF Image Flip Vertical On/Off 8x 01 04 66 03 FF CAM_ColorGain Direct 8x 01 04 49 00 00 00 pp pp: Color Gain setting www.avonic.eu...
  • Page 40 8x 01 04 58 03 FF CAM_SettingReset Reset 8x 01 04 A0 10 FF Reset Factory Setting CAM_Brightness Direct 8x 01 04 A1 00 00 0p 0q pq: Brightness Position CAM_Contrast Direct 8x 01 04 A2 00 00 0p 0q pq: Contrast Position www.avonic.eu...

  • Page 41: Visca Query Command List

    50 0p 0q 0r 0s FF pqrs: Focus Position CAM_WBModeInq 8x 09 04 35 FF y0 50 00 FF Auto y0 50 01 FF Indoor mode y0 50 02 FF Outdoor mode y0 50 03 FF OnePush mode y0 50 05 FF Manual www.avonic.eu...
  • Page 42 50 03 FF CAM_PictureFlipInq 8x 09 04 66 FF y0 50 02 FF y0 50 03 FF CAM_RegisterValueI 8x 09 04 24 mm FF y0 50 0p 0p ff mm: Register No. (00 to FF) pp: Register Value (00 to FF) www.avonic.eu...
  • Page 43 M Type y0 50 03 FF S Type CAM_DateInq 8x 09 00 04 FF y0 50 0r ss uu uu vv Version date ww 0D FF r: Big Version Number ss: Little Version Number uuuu: Year vv: Month ww: Day www.avonic.eu...
  • Page 44 50 0p 0p 0q 0q 0r pp: R_Gain 0s tt 0u vv ww 00 xx 0z qq: B_Gain r: WB Mode s: Aperture tt: AE Mode u: BackLight vv: Shutter Position ww: Iris Position xx Bright Position z: Exp Comp. Position www.avonic.eu...
  • Page 45 50 00 00 00 00 00 p: AF sensitivity ockInq 00 00 0p 0q rr 0s 0t 0u q: Picture flip 1:On, 0:Off rr.6~3: Color Gain (0(60%) to E(200%)) s: Flip 0: Off, 1:Flip-H, 2:Flip-V, 3:Flip-HV t: 2~0: NR2D level u: Gain limit www.avonic.eu...

  • Page 46: Pelco-D Protocol Command List

    0xAF Focus Far 0xA0 Address 0x00 0x80 0x00 0x00 0xAF Focus Near 0xA0 Address 0x01 0x00 0x00 0x00 0xAF Set Preset 0xA0 Address 0x00 0x03 0x00 Preset ID 0xAF Clear Preset 0xA0 Address 0x00 0x05 0x00 Preset ID 0xAF www.avonic.eu...

  • Page 47: Visca Over Ip Commands

    Response VISCA over IP commands The Avonic CM63-IP camera is implemented with a TCP server. The TCP port number is 5678 by default and can be altered in the WebGUI. Once the connection between client and server is set up, the client will be able to send PTZ commands to the server. The server then parses and executes the PTZ command.
  • Page 48 Returned when a command cannot be Executable (y: Execution command executed due to current conditions. Socket No. Inquiry command: For example, when commands controlling the focus manually are received during auto focus. 2. Camera control commands x= Camera Address y= Socket Number www.avonic.eu...
  • Page 49 Manual Control mode Shutter priority 81 01 04 39 0A FF Shutter Priority Automatic Exposure mode Iris priority 81 01 04 39 0B FF Iris Priority Automatic Exposure mode Bright 81 01 04 39 0D FF Bright Mode(Manual control) www.avonic.eu...
  • Page 50 Reset 81 01 04 3F 00 pp FF pp: Memory Number(=0 to 127) 81 01 04 3F 01 pp FF Recall 81 01 04 3F 02 pp FF CAM_LR_Reverse 81 01 04 61 02 FF Image Flip Horizontal On/Off www.avonic.eu...
  • Page 51 81 01 04 A1 00 00 0p 0q FF pq: Brightness Position CAM_Contrast Direct 81 01 04 A2 00 00 0p 0q FF pq: Contrast Position CAM_Flip 81 01 04 A4 00 FF Single Command For Video Flip Flip-H 81 01 04 A4 01 FF www.avonic.eu...
  • Page 52 Iris priority 90 50 0D FF Bright CAM_ShutterPosIn 81 09 04 4A FF 90 50 00 00 0p 0q FF pq: Shutter Position CAM_IrisPosInq 81 09 04 4B FF 90 50 00 00 0p 0q FF pq: Iris Position www.avonic.eu...
  • Page 53 NTSC 90 50 05 FF NTSC 90 50 06 FF NTSC 90 50 07 FF 1920x1080p60 90 50 08 FF 1920x1080i50 90 50 09 FF 1920x1080p25 90 50 0A FF 1280x720p50 90 50 0C FF 90 50 0D FF www.avonic.eu...
  • Page 54 90 50 00 00 00 0p FF p: Color Hue setting 0h (− 14 degrees) to Eh ( +14 degrees) CAM_AWBSensitivi 81 09 04 A9 FF 90 50 00 FF High tyInq 90 50 01 FF Normal 90 50 02 FF www.avonic.eu...
  • Page 55 Step4. Pan-Tilt will rotate to the maximum position of top right after the camera started, then it return to the center, the process of initialization is finished. (Note: If the position preset 0 has been stored, the position preset 0 will be called up after initialization) www.avonic.eu...
  • Page 56 Appendix C Dimensions All sizes are in mm Weight: 2.4 kg www.avonic.eu...
