- Page 1 The Vintage Fire Pit Table Installation Instructions for Vintage Fire Pit Table VNG-1242BRN or VNG-1242-XL...
-
Page 3: Table Of Contents
IMPORTANT Contents Please consult your Crystal Fire instruction manual for detailed instructions and important information related to burner installation, Required Tools…………………………….…..2 including safety information, proper tightening of connections with two wrenches, and full burner setup and lighting instructions. Placing and assembling the Table.………3 DO NOT ATTEMPT TO INSTALL CRYSTAL FIRE BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL. -
Page 4: Gas Connection
Included with your Fire Pit Base CF-1242 Linear Burner... -
Page 5: Assembly Instructions
Assembly Instructions Open packaging and remove the access door before removing the fire pit base from the box. Set the base in the desired location and set top onto base. Replace access door. -
Page 6: Igniter Installation
Gas Connections Gas Connections Read and understand your Crystal Fire owner’s manual before beginning burner hookups or using the device. Do not use Teflon tape or pipe dope on flare fittings. 1. Reach inside the burner cut-out and attach natural gas supply line using a 3/8”... -
Page 7: Locating Propane Tank
Set the burner into the fire pit table exactly as shown. Electrode Access Door 4. Attach flex line from the burner to the gas valve as Ignit shown. TIGHTEN CONNECTION SECURELY WITH WRENCH Metal flex line to burner ONLY... -
Page 8: Igniter Installation
Igniter Installation Make sure the valve is in the OFF position before beginning. Install sparker as shown, using an AAA battery (not included). Sparker will not operate correctly without an ignition and ground wire attached. Plug both BLACK wires hanging from the burner into the back of the sparker box. -
Page 9: Position Your Tank (If Applicable)
After installing igniter and making gas connections, verify that they are tight and that no leaks are present using a solution of soapy water or a commercially available leak-check solution. Position Your Tank (If Applicable) Remove door, connect the propane hose/regulator to the propane tank and hand-tighten (DO NOT USE A WRENCH) and slide the propane tank past the dashed red line to ensure the door closes properly. -
Page 10: Glass Installation
Glass Installation 1. Scatter all the included glass beads evenly onto burner surface. DO NOT OPERATE CRYSTAL FIRE BURNER WITHOUT INCLUDED GLASS BEADS IMPORTANT Please consult your Crystal Fire instruction manual for detailed instructions and important information related to burner installation, including safety information, proper tightening of connections with two wrenches, and full burner setup and lighting instructions. - Page 12 Please visit http://www.outdoorrooms.com/warranty-form/ to register your product. Thank you for purchasing an Outdoor GreatRoom Company product! This fire pit was made with pride in the USA. 14400 Southcross Drive West • Suite 100 • Burnsville, MN 55306 Toll Free: 1-866-303-4028 •...
