- Page 1 The Vintage Fire Pit Table Installation Instructions for Vintage Fire Pit Table VNG-1224BRN...
-
Page 3: Table Of Contents
IMPORTANT Contents Please consult your Crystal Fire instruction manual for detailed instructions and important information related to burner installation, Required Tools…………………………….…..2 including safety information, proper tightening of connections with two wrenches, and full burner setup and lighting instructions. Placing and assembling the Table.………3 DO NOT ATTEMPT TO INSTALL CRYSTAL FIRE BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL. -
Page 4: Gas Connection
Included with your Fire Pit Base Door CF-1224 Burner Kit Tile Top attachment brackets (4) Self-piercing sheet metal screws (8) -
Page 5: Assembly Instructions
Assembly Instructions Open packaging and remove the access door before removing the fire pit base from the box. Set the base in the desired location and set top onto base. Replace access door. 3. Install 4 tile top attachment brackets in the locations shown below, using the cordless drill to drive the 8 self-piercing sheet metal screws. -
Page 6: Igniter Installation
Gas Connections Gas Connections Read and understand your Crystal Fire owner’s manual before beginning burner hookups or using the device. Do not use Teflon tape or pipe dope on flare fittings. 1. Reach inside the burner cut-out and attach natural gas supply line using a 3/8”... -
Page 7: Locating Propane Tank
Set the burner into the fire pit table exactly as shown. Electrode Access Door Attach flex line from the burner to the gas valve as shown. TIGHTEN CONNECTION SECURELY WITH WRENCH Metal flex line to burner ONLY... -
Page 8: Igniter Installation
Igniter Installation Make sure the valve is in the OFF position before beginning. Install sparker as shown, using an AAA battery (not included). Sparker will not operate correctly without an ignition and ground wire attached. Plug both BLACK wires hanging from the burner into the back of the sparker box. -
Page 9: Position Your Tank (If Applicable)
Position Your Tank (If Applicable) Remove door, connect the propane hose/regulator to the propane tank and hand-tighten (DO NOT USE A WRENCH) and slide the propane tank into place. With tank inside base, ensure that no hoses, wires, or anything else is kinked or touching the burner pan. -
Page 10: Operating Instructions
Operating Instructions Before operating your fire pit, ensure all gas connections are properly tightened and thoroughly leak checked. Refer to the Crystal Fire Manual for information on proper leak checking and other critical safety information. With the control valve on the fire pit in the OFF position, open the valve on the propane tank or natural gas supply. - Page 11 IMPORTANT Please consult your Crystal Fire instruction manual for detailed instructions and important information related to burner installation, including safety information, proper tightening of connections with two wrenches, and full burner setup and lighting instructions. DO NOT ATTEMPT TO INSTALL CRYSTAL FIRE BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL.
