CAUTION:
The antenna connector should be hand-tightened only to the unit SMA port. Use of a wrench for this
purpose will result in damage to the unit housing and/or the connector, hence null the product
warranty. Application of stress to the DF Antenna should also be avoided to preclude permanent
damage to Unit and/or the DF Antenna assembly.
Powering Up Unit
The unit is powered up by pushing in the trackball or black center pushbutton (model dependent) for at
least 1 second. When powered, the amber monochrome OLED will display one of the three
measurement screens (Phone Detection, Direction Finding or DECT 6.0 Detection) from which the unit
was turned off the last time it was used.
Activating Accessories (Sound/Vibrator/Laser)
From the MAIN MENU (see Figure 5 above) select "Effect Options" to obtain the EFFECT OPTIONS menu
(Figure 17):
Figure 17. EFFECT OPTIONS menu
Selecting "Effects On/Off" will cause the OLED to display the "EFFECTS ON / OFF" screen seen in Figure
20
