FLEX 5000 Terminal Base Assembly Modules
Catalog Numbers Terminal Bases Assemblies: 5094-TB3, 5094-TB3S, 5094-TB3XT, 5094-TB3SXT, 5094-TB3T, 5094-TB3TS, 5094-TB3TXT,
5094-TB3TSXT, 5094-TB3W, 5094-TB3WS, 5094-TB3WXT, 5094-TB3WSXT
Mounting Bases: 5094-MB, 5094-MBXT
Removable Terminal Blocks: 5094-RTB3, 5094-RTB3XT, 5094-RTB3S, 5094-RTB3SXT, 5094-RTB3T, 5094-RTB3TXT, 5094-RTB3TS, 5094-
RTB3TSXT, 5094-RTB3W, 5094-RTB3WXT, 5094-RTB3WS, 5094-RTB3WSXT
Topic
Product Overview
The FLEX 5000 terminal base assemblies comprise of either a 5094-MB or a 5094-MBXT and one of the removable terminal blocks needed as a
terminal base for your specific FLEX 5000 I/O modules. Terminal base assemblies are a required part of the FLEX™ 5000 I/O system.
FLEX 5000 I/O systems are used with some Logix5000™ controllers and configured with the Studio 5000 Logix Designer® application. For more
information on how which Logix5000 controllers and Logix Designer application versions are compatible with FLEX 5000 I/O modules, see the
publications listed in
Additional Resources on page
Page
5
6
6
9
11
12
13
14
15
15.
