Installation Instructions
Original Instructions
PanelView Plus and PanelView Plus
Compact 400 and 600 Terminals
Catalog Numbers 2711P-x4xxxx, 2711P-x6xxxx, 2711PC-x4xxxx, 2711PC-x6xxxx
Topic
Summary of Changes
This document contains new and updated information as indicated in the following table.
Topic
Updated information about external power supply requirements.
Page
1
2
3
4
5
9
9
10
11
16
17
20
22
26
27
29
Pages
17...18
Advertisement
Table of Contents
Related Manuals for Allen-Bradley PanelView Plus 400
Summary of Contents for Allen-Bradley PanelView Plus 400
-
Page 1: Table Of Contents
Installation Instructions Original Instructions PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Catalog Numbers 2711P-x4xxxx, 2711P-x6xxxx, 2711PC-x4xxxx, 2711PC-x6xxxx Topic Page Summary of Changes Important User Information About This Publication Environment and Enclosure Hazardous Locations Wiring and Safety Guidelines About the Product Parts List Install the Terminal... -
Page 2: Important User Information
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Important User Information Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. -
Page 3: About This Publication
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals About This Publication This document provides instructions on how to install these devices in a panel: • PanelView™ Plus 400 keypad terminal or keypad and touch terminal • PanelView Plus 600 keypad, touch, or keypad and touch terminal •... -
Page 4: Environment And Enclosure
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6561 ft) without derating. -
Page 5: Hazardous Locations
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Hazardous Locations This equipment is suitable for these locations: • Class I, Division 2 Groups A, B, C, D • Class II, Division 2 Groups F, G • Class III •... - Page 6 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Environnements dangereux Cet équipement ne peut être utilisé que dans les environnements suivants : • Classe I, Division 2, Groupes A, B, C, D ; • Classe II, Division 2, Groupes F, G ; •...
- Page 7 National Electrical Code, article 500. 400 and 600 Terminals Control Drawing Associated Nonincendive Field Wiring Apparatus Nonincendive Field PanelView Plus 400/600 Host Product Wiring Apparatus Nonincendive Field Wiring Peripheral USB Port...
- Page 8 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Application Information Per the National Electrical Code, the circuit parameters of nonincendive field wiring apparatus for use in hazardous locations shall be coordinated with the associated nonincendive field wiring apparatus such that their combination remains nonincendive. The 400 and 600 terminals and the USB peripheral device shall be treated in this manner.
-
Page 9: Wiring And Safety Guidelines
2711P-TD001. You can find this publication in the Literature Library at http:// literature.rockwellautomation.com. About the Product The base configured unit of the PanelView Plus 400 and 600 terminals includes these components: • Power supply, AC or DC • Display with keypad, touch screen, or keypad and touch screen •... -
Page 10: Parts List
• USB, RS-232, and Ethernet Ports with Interface for IMPORTANT When using the DH-485 module, catalog number 2711P-RN3, with PanelView Plus 400 and 600 terminals, the cable length must not exceed 30 m (98 ft) to comply with CE requirements. For longer cable lengths, use the 1761-NET-AIC or 1747-AIC module. -
Page 11: Install The Terminal
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Install the Terminal Before installing the terminal in a panel, review these topics: • Mounting clearances • Panel cutout dimensions • Product dimensions Mounting Clearances Allow adequate clearance around the terminal, inside the enclosure, for adequate ventilation. Consider heat produced by other devices in the enclosure. - Page 12 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Follow these steps to mount the terminal in a panel. 1. Cut an opening in the panel using the panel cutout that shipped with the terminal. 2. If a communication module is ordered separately, attach the module to the base unit before panel installation.
- Page 13 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 8. Rotate each lever in the direction indicated until it is in the final latch position. Follow the latching sequence for the optimum terminal fit. 4 Levers Notch Alignment Marks Rotate until notch in lever aligns 6 Levers with proper alignment mark on...
- Page 14 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Product Dimensions The illustrations show approximate product dimensions for the PanelView Plus and PanelView Plus Compact 400 and 600 terminals. Measurements are in mm (in.). 400 Terminal Dimensions 400 Keypad or Keypad and Touch (6.0) (7.28)
- Page 15 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals 600 Terminal Dimensions 600 Keypad or Keypad and Touch (6.58) (10.47) (2.68) (3.86) 71 (2.81) 154 (6.08) 600 Touch (6.0) (7.28) 68 (2.68) 71 (2.81) 154 (6.08) Rockwell Automation Publication 2711P-IN002H-EN-P - April 2018...
-
Page 16: Remove And Install The Power Terminal Block
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Remove and Install the Power Terminal Block The terminals ship with a power block installed. You can remove the power terminal block for ease of installation, wiring, and maintenance. WARNING: Explosion Hazard Substitution of components may impair suitability for hazardous locations. -
Page 17: Dc Power Connections
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Follow these steps to replace the terminal block. 1. Press terminal block base in first with the block leaning outward. 2. Gently push the top of terminal block back to vertical position to snap in locking tab. DC Power Connections PanelView Plus devices with an integrated, nonisolated, DC power supply have these power ratings:... - Page 18 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals External Power Supply Use a single, 24V DC power supply to power each PanelView Plus terminal, such as catalog number 2711P-RSACDIN. Using a separate, isolated, and ungrounded source to power each terminal helps prevent ground loop currents from damaging the terminals.
- Page 19 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Connect DC Power WARNING: Explosion Hazard - Do not disconnect equipment unless power has been switched off and area is known to be nonhazardous. Disconnect all power before installing or replacing components. Failure to disconnect power may result in electrical shock and/or damage to the terminal.
-
Page 20: Ac Power Connections
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals AC Power Connections The 400 to 600 terminals with an integrated AC power supply have these power ratings: • 85…264V AC (47…63 Hz) • 60V A maximum The input power terminal block is removable and supports these wire sizes. Wire Specifications for AC Input Power Terminal Block Terminal Screw Wire Type... - Page 21 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Connect AC Power WARNING: Explosion Hazard - Do not disconnect equipment unless power has been switched off and area is known to be nonhazardous. Disconnect all power before installing or replacing components. Failure to disconnect power may result in electrical shock and/or damage to the terminal.
-
Page 22: Troubleshooting
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Troubleshooting If the terminal is not operating correctly, check the power, display settings, status indicators, and review the system startup and error messages. Check for Adequate Power A terminal that does not receive adequate power could cause unpredictable behavior. Verify the power requirements in the Specifications table. - Page 23 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals The table shows indicator states if the terminal powers on and stops during startup. Indicator States If the Terminal Stops During Startup Fault (Red) Comm (Green) Description Indicator Indicator Last firmware download failed. Reload firmware using Firmware Upgrade Wizard (FUW) utility.
- Page 24 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Startup Information Messages Startup information messages display in a specific sequence on the terminal screen during startup and typically display for a few seconds. These messages do not require that you perform any action.
- Page 25 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Startup Error Messages When an error occurs, the terminal displays an error number with a text message. The word ERROR! appears under the message in different languages. # Displayed Message ERROR! FEHLER! ERREUR! ERRORE! Error # Message...
-
Page 26: Battery Removal
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Battery Removal The 400 and 600 terminals contain a lithium battery that is permanently connected and should be removed only by trained professionals. This product contains a hermetically sealed lithium battery which may need to be replaced during the life of the product. -
Page 27: Specifications
PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Specifications PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Attribute Value Display 400 and 600 grayscale display Grayscale passive matrix, film compensated super-twist nematic (FSTN) LCD technology Color active matrix, thin film transistor (TFT) LCD technology 400 and 600 color display Display size, Approx., diagonal 400 grayscale display... - Page 28 PanelView Plus and PanelView Plus Compact 400 and 600 Terminals PanelView Plus and PanelView Plus Compact 400 and 600 Terminals Dimensions (HxWxD), approx. 400 keypad, or keypad and touch 152 x 185 x 90 mm (6.0 x 7.28 x 3.54 in.) 600 keypad, or keypad and touch 167 x 266 x 98 mm (6.58 x 10.47 x 3.86 in.) 600 touch...
-
Page 29: Additional Resources
PanelView Plus and PanelView Plus CE terminals. publication 2711P-TD001 You can view or download publications and translated versions of the installation instructions at http://literature.rockwellautomation.com. To order paper copies of technical documentation, contact your local Allen-Bradley distributor or sales representative. Rockwell Automation Publication 2711P-IN002H-EN-P - April 2018... - Page 30 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, PanelView, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
