Summary of Contents for BEAUTY ANGEL CVT 42 (COL30L)
- Page 1 B E A U T Y A N G E L O P E R AT I N G I N S T R U C T I O N S...
- Page 3 WARNING! This device is designed for use with NON-UV emitting lamps only! Use of UV lamps, or any lamps other than those specified for use in this device, may cause serious injury and is considered a violation of FDA regulations including: Code of Federal Regulations Title 21 CFR1040 TITLE 21--FOOD AND DRUGS CHAPTER I--FOOD AND DRUG ADMINISTRATION...
-
Page 4: Contact Information
Contact Information Contact Information Manufacturer: JK-Products and Services 1 Walter Kratz Drive Jonesboro, AR 72401 Tel.: 800.643.0086 Fax: 870.935.3618 Customer service / Techni- JK-Global Service cal service (Spare part 1 Walter Kratz Drive orders for components): Jonesboro, AR 72401 Tel.: 800.445.0624 Fax: 870.935.9046 E-mail: support@jkamerica.com Web: http://support.jkamerica.com... -
Page 5: Table Of Contents
Table of contents Table of contents Contact Information..................2 Table of contents ...................3 General...................5 Product Claims, Expectations, and Usage ........5 Definitions ..................5 Symbol explanation................6 Information for the operator............7 Intended use ...................8 Foreseeable misuse................8 Operator's obligations ..............8 Personnel training ................8 Scope of delivery................8 Transport, assembly and setup............ - Page 6 Lamps....................30 Cleaning plan ................31 Maintenance..................32 5.5.1 Acrylic panel..................32 Maintenance plan ................33 Instructions for replacing the lamps..........34 Beauty Angel lamps............... 34 5.7.1 5.7.2 Starter....................35 Clean or replace lamps in the door..........35 Clean or replace lamps on the side panels ........37 5.10 Clean or replace Ambient Light .............39...
-
Page 7: General
General General Product Claims, Expectations, and Usage The Beauty Angel utilizes a 3-step system to achieve the desired result. STEP 1: VibraShape Technology: Platform Based, Powered Therapeutic Massage, Muscle Stimulation and Exercise Technology. STEP 2: Full Body, Controlled Light Energy. -
Page 8: Symbol Explanation
General Symbol explanation The following types of safety notices are employed in these operating instruc- tions: DANGER! Type and source of hazard This safety notice indicates the existence of a direct danger to body and life. DANGER! Type and source of hazard This safety notice warns of dangers to body and life which are caused by electricity. -
Page 9: Information For The Operator
Information for the operator Information for the operator Intended use BEAUTY ANGEL This device is intended to temporarily firm and tone the appearance of the muscles and body. Some people are not permitted to use the device, see page 18. -
Page 10: Intended Use
Information for the operator Operator's obligations As the operator you are responsible for providing clear operating, cleaning and maintenance instructions. You are also responsible for ensuring the intended use and the proper operation of the device by means of training and instruction for the personnel and provision of all appropriate safety devices (including eyewear). -
Page 11: Transport, Assembly And Setup
Information for the operator 2.6.1 Assembly DANGER! Personal danger due to electric shock or burns! – The assembly and electrical connection must comply with local and national regulations. – The electrical installation must have an easily accessi- ble disconnect or breaker that complies with overvolt- age category III. -
Page 12: Setup Location
Information for the operator 2.6.3 Setup location The device may not be operated outside. Installation and Setup The initial installation and setup is performed by the manufacturer's own ser- vice personnel or by an authorized dealer/distributor. The device is only re- leased to the owner when installation is complete and the system is ready for use. -
Page 13: Decommissioning
2.10.1 Environmental regulations – disposal of lamps and batteries Beauty Angel lamps contain fluorescent materials and other waste products containing mercury. Batteries contain heavy metal compounds. Some areas of the USA and Canada have specific regulations regarding disposal of these waste. Please check the laws in your area and act in ac- cordance with municipal waste regulations. -
Page 14: Mp3 Music (Optional)
Information for the operator 2.12 MP3 music (optional) If an MP3 player is used privately during the application, then this does not constitute a public performance in the sense of copyright law, so that no re- porting or fee obligation exists on the part of the studio operator towards the organization responsible for issuing the commercial performance rights. -
Page 15: Manufacturer's Warranty
Information for the operator 2.15 Manufacturer's Warranty On behalf of customers who have purchased a Beauty Angel device for private or commercial use from one of our sales partners, JK Products accepts liability for any defects that arise in accordance with the following regulations;... -
Page 16: Description
Description Description Scope of delivery Beauty Angel device Technical documentation (Printed documentation and Operation Instruc- tions CD) Beaty Angel lamps Ambient light (Effect lighting) VibraShape Allen key Connecting lead 3D sound Equipment... -
Page 17: Device Description
Description Device description 1. Adjustable feet 2. Base plate 3. Foot mat (silicone) and vibration plate (VibraShape) 4. Beauty Angel lamps 5. Control panel, headphone connection 6. Handles 7. Loudspeaker (optional) 8. Fans (body cooling) 9. Interior lighting (LED) 10. Door handle 11. -
Page 18: Accessories (Optional)
Description Accessories (optional) 3D sound 7 Audio system with Voice Guide 7.1 Headphone connection 7.2 MP3-connection 7.3 Sound Box 7.4 Subwoofer 7.5 Loudspeakers MP3 cable (not pictured) Function description See page 25 for information on control and operation of the Light Energy device and its features. -
Page 19: Vibrashape
Description VibraShape You may choose from four (4) different programs, each offering varying levels of targeted muscle stimulation, exercise and massage intensity. The body immediately responds to the patented, pre-programmed movement of the platform. Muscles automatically flex and relax as the Vibra-Shape technology stimulates muscle activity. -
Page 20: Operation
Operation Operation Safety information for the user DANGER! Danger of hearing damage! Using earphones or headphones at high volume can result in permanent hearing damage. – Do not set the volume too high. Light Emitting device 4.1.1 NOTE: Extending the specified application times is not permitted. -
Page 21: Vibrashape (Vibration Plate)
Operation 4.1.2 VibraShape (Vibration plate) Side effects DANGER! Risks of damage to health! Vibrations can cause or aggravate health problems. Consult physician prior to beginning any new fitness program or if you have any concerns.Vibrations can cause or aggravate health problems. The following people are not allowed to use the equipment: Pregnant women ... - Page 22 Operation Side effects The use of the vibration plate may lead to the following side effects: Itching in regions of the body being trained Nausea and vertigo Rapid and brief drop in blood pressure Rapid hyperglycemia in the event of diabetes ...
-
Page 23: Application Times
11. Week 12. Week 1-2 x per week After treatment: Application tips Beauty Angel device – Stand up straight and in the center of the device during the application. Bend knees slightly. – Use overhead straps for support and to increase muscle tension. - Page 24 Operation VibraShape DANGER! Risk of injury! The vibration function is not suitable for all users. Please observe the restrictions on page 18. – NOTE: Each 12 minute program starts with a warm-up phase and ends with a cooling-down phase. A vibration program normally lasts for 10 minutes of the 12 minute session.
-
Page 25: Operating Overview
Operation Operating overview 1. START/STOP button 2. Left navigation arrow button 3. Plus button 4. Audio system icon 5. Music icon 6. VibraShape icon 7. Display – Functions … 8. Body cooling icon 9. Volume icon 10. Voice Guide icon 11. -
Page 26: Navigation
Operation 4.4.1 Navigation The device is operated with the navigation ring. Switch on lamps: Press the button once. Switch off lamps/interrupt application: Hold the button. Select device function (go to pictogram) e.g. MUSIC Select sub-function (if available) Change setting The LED indicator for the available functions and the navigation ring are illu- minated in default mode after starting up the device. -
Page 27: Functions
Operation Functions Function Button sequence Description Information 1. Lamps START/STOP If the lamps are switched off Switch lamps on/off during the during the application, the ap- application (in combination with plication time continues to run. VibraShape: see below). 2. VibraShape Select VibraShape Press the button once: Vibra- START/STOP also switches off... -
Page 28: Start
Operation Function Button sequence Description Information 7. Audio system Selecting the audio system (channel) Internal: Music SD card Select title – External: Externally connected systems, e.g. CD player Refer to ‘Presettings' Guide on Select channel – Operating Instructions CD. (maximum) MP3 player 8. -
Page 29: Connect Mp3 Player
Operation Connect MP3 player DANGER! Danger of hearing damage! Using earphones or headphones at high volume can result in permanent hearing damage. – Do not set the volume too high. Users may connect MP3 players to the light energy device. 1. -
Page 30: Cleaning And Maintenance
Cleaning and maintenance Cleaning and maintenance Safety information for cleaning and maintenance DANGER! Electricity throughout entire device Personnel danger due to electric shock or electric burns. – Before beginning work disconnect all of the power con- nections from main voltage. –... -
Page 31: Faults
Cleaning and maintenance Faults Error codes are output to the display to simplify troubleshooting: If a fault occurs, the error code flashes on the display. If several errors occur, the error messages are displayed alternately. Error elimination is acknowledged by pressing the START/STOP button. ... -
Page 32: Cleaning The Surfaces
Cleaning and maintenance 5.3.2 Cleaning the surfaces Acrylic glass panel WARNING! Do not rub with a dry cloth – danger of scratching! Failure to comply voids any warranty claims. – For fast, hygienic proper cleaning of acrylic glass sur- faces, use specially developed disinfectant cleaner Lucasol ®... -
Page 33: Cleaning Plan
Cleaning and maintenance Cleaning plan Component Interval Activity page 1 Entry area Cleaning and disinfection 2 Foot mat (Silicone) Cleaning and disinfection 3 Control panel Cleaning and disinfection 4/5 Handle Cleaning and disinfection Protective goggles Cleaning and disinfection MP3 cable Cleaning and disinfection 6 Surfaces Cleaning and disinfection... -
Page 34: Maintenance
Cleaning and maintenance NOTE: If desired, cleaning must be confirmed after each application by pressing the START/STOP button (when the warm-down time for the main fan has finished). Maintenance Maintenance and care play a major role in deciding whether the device meets the requirements placed on it. -
Page 35: Maintenance Plan
Cleaning and maintenance Maintenance plan WARNING! Only use genuine spare parts of the same type! If other parts are used then the device no longer complies with the conformity declaration and may not be operated any longer! Any liability for damage or injury proven to be the result of the use of non-genuine spare parts is excluded. -
Page 36: Instructions For Replacing The Lamps
Instructions for replacing the lamps The lamp output decreases over the course of time. As such, the replacement intervals specified in the maintenance plan must be adhered to. Beauty Angel lamps 5.7.1 Never replace with UV lamps of any type! ... -
Page 37: Starter
Cleaning and maintenance 5.7.2 Starter Replace faulty starters immediately. You can recognize a faulty starter by the blackened ends of the lamps or when the lamps can no longer be started. Operating a lamp with a faulty starter significantly shortens its service life. The lamp loses power and may begin to flicker under certain circumstances. - Page 38 Cleaning and maintenance Upper lamp cover: – Loosen screws 3-4 mm. – Take off the lamp cover. Replace the lamps: See page 34. Replace the starter: See page 35. The assembly is the same process in reverse order.
-
Page 39: Clean Or Replace Lamps On The Side Panels
Cleaning and maintenance Clean or replace lamps on the side panels WARNING! Acrylic panels may be damaged! Residue on the panels, combined with the heat generated by the lamps can result in long term damage to panels. Clean throughly between each use. –... - Page 40 Cleaning and maintenance – The panel must be taken out past the cockpit control. Ensure that you do not scratch the panel. – Carefully pull the panel past the back of the cockpit control and remove to the left. Upper lamp cover: –...
-
Page 41: Clean Or Replace Ambient Light
Cleaning and maintenance Clean or Replace Ambient Light 5.10 – Remove the screws. – Remove the lamp cover. Replace the lamps: See page 34. Replace the starter: See page 35. The assembly is the same process in reverse order. 02/2012 Revision 7 0071106701 Operating Instructions - 39... -
Page 42: Technical Data
Technical data Technical data Power rating, electrical specifications and noise level BEAUTY ANGEL Nominal power consumption: 8700 W Rated frequency: 60 Hz Rated voltage: 230 V 30 Amp 3-Pole or Rated fuses: 50 Amp 2-Pole Connecting lead: Noise level at 1 m distance from the device:... -
Page 43: Dimensions
Technical data Dimensions 12246 / 0 55 in. B1 = 35 in. B4 = 7 in. B6 = 34 in. B8 = 54 in. 51 in. T1 = 55 in. T2 = 73 in. T3 = 34 in. 92 in. H1 = 3 in. -
Page 44: Lamp Sets
Technical data Lamp sets WARNING! USE ONLY the specfied Beauty Angel NON-UV lamps! The conformity declaration and the ETL Intertek test mark only apply for the specified lamps. The mark is voided if other lamps are used. Use of UV lamps in this device is a violation of 21 CFR 1040, FDA. -
Page 45: Accent Lighting
Technical data 6.3.2 Accent lighting Number Description Power Order-no. Low pressure lamps blue 58 W 12063-.. Starter S10 10047-.. Low pressure lamp blue 58 W 12063-.. Starter S10 10047-.. Spare parts and accessories Number Description Order-no. 0041013201 Acrylic panels 02/2012 Revision 7 0071106701 Operating Instructions - 43... -
Page 46: Appendix
Appendix Appendix Signs and stickers on the device Signs warning of danger areas are attached to the device. The signs shown below are examples. Ensure that the instruction signs are always clearly rec- ognizable and easily legible. 1: Serial Number 1.800.643.0086 Model: XXXXXX... - Page 47 Appendix 2: Name Plate / ETL Information JK Products and Services, Inc. #1 Walter Kratz Dr. COL30L Jonesboro, AR 72401 1.800.643.0086 ETL RECOGNIZED xxxxxxxx MEDICAL CLASS 1 ELECTRICAL EQUIPMENT 37925 60Hz 230V 10 xxxxxx 60Hz 230V 30 THIS PRODUCT IS IN CONFORMITY WITH PERFORMANCE STANDARDS FOR MEDICAL ELECTRICAL EQUIPMENT UNDER UL 60601-1 AND CSA C22.2 NO.
- Page 48 Appendix 6: USA mains connection label (1504659-..) D35A D35A D35A D35A D35A D35A 480Y/277V~ 480Y/277V~ 480Y/277V~ 480Y/277V~ 480Y/277V~ 480Y/277V~ Multi 9 C60 Multi 9 C60 Multi 9 C60 Multi 9 C60 Multi 9 C60 Multi 9 C60 0 - OFF 0 - OFF 0 - OFF 0 - OFF...
- Page 49 Appendix 9: Exposure Label Label is located on the outside edge of the left panel. NOTICE: THIS SYSTEM DOES NOT EMIT ULTRA-VIOLET LIGHT. This system emits bright light in the 580 – 700 nanometer range. Protective eye wear such as sunglasses or other light reducing eye wear is recommended for people who are sensitive to bright light.
- Page 50 WARNING! This device is designed for use with NON-UV emitting lamps only! Use of UV lamps, or any lamps other than those specified for use in this device, may cause serious injury and is considered a violation of FDA regulations including: Code of Federal Regulations Title 21 CFR1040 TITLE 21--FOOD AND DRUGS CHAPTER I--FOOD AND DRUG ADMINISTRATION...
