Altronix AL300XB2V Installation Manual page 4

Fig. 1 - XBV configuration
5A 250V
L
1a
* Output Voltage Selection DIP Switch. Not applicable for AL1012XB220 and AL1024XB2V.
** AL1012XB220 terminals marked [– DC +]
*** AL1024XB2V terminals marked [– BAT +]
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIXBV
- 4 -
G N
AC DC BAT
BAT FAIL NC C NO NC C
1b
H15R
1e*
OFF --- 24V
ON --- 12V
NO AC FAIL
XBV Power Supply/Chargers
1d**
1c***
