Altronix AL300ULXD power supply/charger converts a 115VAC, 50/60Hz or 230VAC, 50/60Hz input into a
power-limited 12VDC or 24VDC output (see specifications).
Agency Listings:
• UL 294* Safety Access Control System Units,
UL 603
Power Supplies for Use with
Burglar-Alarm Systems,
UL 1069 Hospital Signaling and
Nurse Call Equipment,
UL 1481 Power Supplies for Fire-Protective
Signaling Systems.
• CE
European Conformity.
Input:
• 115VAC, 50/60Hz, 0.9A or
230VAC, 50/60Hz 0.45A.
Output:
• 12VDC or 24VDC selectable output.
• 12VDC or 24VDC @ 2.5A supply current.
• Class 2 Rated power-limited output.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
*Access Control Performance Levels:
Destructive Attack - I; Endurance - IV; Line Security - I; Stand-by Power - IV.
Power Supply Output Selection:
Output
12VDC
24VDC
Output
12VDC / 40AH Battery
24VDC / 12AH Battery
24VDC / 40AH Battery
AL300ULXD
Power Supply/Charger

Specifications:

Switch Position
SW1, 2 - ON, SW3, 4 - OFF
SW1, 2 - OFF, SW3, 4 - ON
Stand-by Specifications:
4 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 2.5A
Alarm = 2.5A
Stand-by = 2.5A
Alarm = 2.5A

Overview:

Battery Backup:

• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switch over to stand-by battery
when AC fails.
• Maximum charge current 0.6A.

Supervision:

• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).

Visual Indicators:

• AC input and DC output LED indicators.

Features:

• Low battery disconnect.
• Unit is complete with transformer, power supply,
grey enclosure, and cam lock.
• Battery leads included.
Enclosure Dimensions (H x W x D approx.):
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm).
Accommodates up to two 12VDC/12AH batteries.
For a red enclosure add an "R" suffix to the
part #, e.g. AL300ULXDR.
24 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 1.0A
Alarm = 2.5A
Stand-by = 200mA
Alarm = 2.5A
Stand-by = 1.0A
Alarm = 2.5A
60 hr. of Stand-by and
5 Minutes of Alarm
Stand-by = 300mA
Alarm = 2.5A
Stand-by = 300mA
Alarm = 2.5A
