Replacement Parts List - Hotronix MAXX Operator's Manual

ITEM # PART # DESCRIPTION
1 4-1172-B Control Housing, MAXX
3 1-2018 Controller Overlay, MAXX
4 1-2105 Grommet, 9/32" ID 3/8" OD
5 3-1011-235 Screw, Sheet Metal #6 x 1/2"
6 2-1006-50 Nut, #6-32 Hex with Lockwasher
7 3-1011-130 Screw, Pan Phillips #4-40 x 1"
8 1-1759 Power Inlet
9 1-2087 Power Switch
10 3-1011-19 Screw, Machine #6-32 x 1/2"
11 3-1011-25 Screw, Machine #6-32 x 1/4"
12 1-1353 Conduit Fitting, 1/2" Topaz Straight Twist-On
13 Kit 3-6946 Controller Kit, MAXX
14 2-1006-51 Nut, #4-40 with Tooth Washer
15 2-1661 Controller Bracket, STX MAXX
16 1-1059 TRIAC
17 3-1011-22 Screw, Machine #4-40 x 3/8"
18 1-1290 Terminal Block, 5 Contact High Voltage
20 1-1211 Proximity Switch
21 1-1331 Circuit Breaker 20A (STX XF XRF)
23 KIT 3-6904 Handle Assembly MAXX
27 1-2094 Steel Pin 1/2" D x 6.45"
28 1-1048-3 Washer, 1/2" Nylon
29 1-1107-1 Hub Cap 1/2"
30 1-2093 Steel Pin, 1/2" x 5.375"
31 1-1042-1 All Thread Pin
32 1-2096 PVC Spacer 1/2 I.D. x 5"
33 1-1540 Foam Grip, Black
34 2-1006-2 JCN - NUT
35 1-1219 Proximity Magnet
36 1-2085-1 Magnet Bracket (MAXX)
37 3-1011-232 Shipping Bolt (Thumb Screw), 1/4"-20 x 1/2"
38 KIT 3-6901 Base, MAXX 16x20, 15x15, 11x15
46 3-1011-252 Screw, Pan Phillips #6-32 x 3/4"
47 3-1011-182 Acorn Nut 10-32
48 3-1011-164 Screw, Button Socket Head #10-32 x 1/2"
49 1-1256 Rubber Foot
50 1-2332 Quick Release Clamp, Manual Presses
51 2-1006-20 Nut, Hex Nylok 5/16"-18
52 1-1939 Ball Stud 10mm
54 KIT 3-6951 Pressure Link MAXX
56 KIT 3-6903-1 Adjustment Arm Kit, MAXX
60 3-1011-215 Soc HD Cap Screw 1/4-20 x 3/8 "
61 2-1006-7 Nut, Hex 1/4"-20 Nylok
62 3-1011-106 Screw, Button Socket Head 1/4"-20 X 3/4"
63 3-1011-55 Screw, Shoulder 3/8" x 1-1/4" w/ 5/16"-18 Thread
64 3-6956 Bridle Links MAXX

Replacement Parts List

QTY
1
1
2
6
9
2
1
1
7
5
1
1
8
1
1
6
1
1
1
1
2
10
8
2
1
1
1
2
1
1
1
2
1
4
4
5
1
3
4
2
1
2
2
2
1
2
ITEM # PART # DESCRIPTION
65 1-2091 Pin, 1/2" x 3" w/ 1/4-20 Threads
66 1-2098 PVC Spacer 1/2 " I.D.x 2.48
67 1-2092 Pin, 1/2" x 3-5/8" w/ 5/16"-18 Threads
68 1-2114 Steel Spacer
69 2-1006-46 Washer, 5/16" SS
72 1-2243 Gas Spring 16x20 & 16x16
73 3-1199-1 Lower Platen 11 x 15
73 3-1086 Lower Platen 15 x 15
73 2-1029 Lower Platen, 16x20
74 1-1875 Silicone Pad 11 x 15 Gray
74 1-1473 Silicone Pad 15 x 15 Gray
74 1-1011 Silicone Pad 16 x 20 Gray
75 3-1336 Adapter Plate
76 1-2215 Quick Release Pin
77 2-1006-25 Washer, Flat 1/4" SAE
78 2-1006-44 Washer, Split Lock 1/4"
79 3-1011-191 Screw, Socket Head Cap 1/4"-20 x 1"
80 3-1199 Heat Platen 11 x 15
80 3-1320 Heat Platen 15 x 15
80 2-1002-3 Heat Platen 16 x 20 1800W Milled
81 1-2258 Insulation 11 x 15
81 1-2257 Insulation 15 x 15
81 1-1020 Insulation 16 x 20
82 3-1331-B Heat Platen Cover 11 x 15 MAXX
82 3-1337-B Heat Platen Cover 15 x 15 MAXX
82 3-1332-B Heat Platen Cover 16 x 20 MAXX
84 2-1081 Adjustment Spindle
87 1-1012 Adjustment Knob
88 3-1011-238 Bolt, Hex Head 5/16-18 x 3-1/2"
89 1-2076 Thermostat Disc
90 1-1272-1 Temperature Probe
91 3-1011-87 Screw, SS Phillips #8-32 X 1/4"
92 3-1011-98 Screw, SS Sheet Metal #4 X 1/4"
94 3-1011-217 Screw, Flat Head Phillips #10-24 x 7/16"
95 1-1063 Washer, Plastic Finishing
96 1-1048-2 Conduit, STX & MAXX 11x15, 12"
96 1-1048-2 Conduit, STX & MAXX 20/16/15, 12"
97 1-1940 Conduit Fitting, 1/2" Elbow
200 2-1671 120V Locking Power Cord
201 1-2186 220V Power Cord
202 2-1672 230V European Locking Power Cord
203 1-1279 Lower Platen Spacer
204 KIT 3-6924 Platen Lift Kit
205 1-2367 Quick Change Keyway (Old Style)
206 3-1011-127 Screw, Machine #8-32 x 3/8" Black Oxide
207 1-1068 Heater Wire (Not Shown)
QTY
1
2
1
2
2
2
1
1
1
1
1
1
1
1
4
4
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
4
4
1
1
1
1
1
1
1
1
1
2
1
WWW.HOTRONIX.COM 11
