  • Page 1 AIR FUSION IQ ™ OPERATOR’S MANUAL...

  • Page 2: Safety Instructions

    HOTRONIX ® Safety Instructions AIR FUSION IQ ™ When using your heat press, basic precautions should always be followed, including the following: 1. Read all instructions. 2. Use heat press only for its intended use. 3. To reduce the risk of electric shock, do not immerse the heat press in water or other liquids.

  • Page 3: Table Of Contents

    Table Of Contents Safety Instructions Machine View Operating Instructions Connecting the System Start Up/Shut Down Home Screen Prepare to Print Touch Screen Guide 8-11 Setup Menu Password Setup Preset Setup Date & Time Setup Display Setup Auto On & Off Setup System Setup Calibration Updating Software...

  • Page 4: Machine View

    HOTRONIX ® Machine View AIR FUSION IQ ™ ON/OFF Switch Print Button Upper Platen Air Connect Lower Platen Circuit Breaker & IEC Inlet Height Adjustment Stand Quick Release Touch Screen Caster Platen Release Base Foot Pedal SERVICE HOTLINE: 800.727.8520...

  • Page 5: Operating Instructions

    300 V cord for replacement. Start Up/Shut Down To start up your heat press: Flip the power switch ON (2.1). A splash screen displaying the Hotronix ® logo and current software version is shown for several seconds. To turn your heat press off, flip the power switch OFF.

  • Page 6: Home Screen

    HOTRONIX ® Operating Instructions AIR FUSION IQ ™ Home Screen Status bar provides Displays the selected helpful information preset. Touch and regarding heat press. hold to see application settings. NOTE: Holding down material name will display targeted Displays the current application settings.

  • Page 7: Prepare To Print

    Swing the platen back into position and press both print buttons to lower platen and heat apply (4.2). The Home Screen will initiate a count down and signal when to lift the platen off the garment. Swing or pull the heat platen and proceed according to the application instructions. WWW.HOTRONIX.COM...

  • Page 8: Touch Screen Guide

    HOTRONIX ® Touch Screen Guide AIR FUSION IQ ™ Setup Menu Touch the Settings icon on the Home Screen (5.1) to configure your heat press. Managers can access all setup options, while Users can access a limited set (5.2). •...

  • Page 9: Preset Setup

    Name your preset and enter desired temperature, time, and pressure. When creating a new preset, the current Home Screen application settings are selected automatically (7.6). Touch the empty circled numbers to set multiple preset stages for pretreatment or multi-step applications (7.7). WWW.HOTRONIX.COM...

  • Page 10: Date & Time Setup

    HOTRONIX ® Touch Screen Guide AIR FUSION IQ ™ Date & Time Setup Touch the Settings icon on the Home Screen. • Touch Date & Time, information displays on right of screen (8.1). • Touch up/down arrows to select time zone.

  • Page 11: Calibration

    • Touch Downloaded Update File on right of screen, then touch Check Mark icon on taskbar to start installation. NOTE: If a power failure occurs during installation, the heat press will attempt to install the previous software version. WWW.HOTRONIX.COM...

  • Page 12: Connecting To The Iq Portal

    Portal AIR FUSION IQ ™ ™ Create Your Account • Using a phone or computer, visit iq.hotronix.com to create an account (13.1). • Enter your name, email, and password. • Click on the confirmation link in the email you receive.

  • Page 13: Electrical Schematic

    RTD Probe Quick Release Ground Switch to Frame Proximity Switch 1800W Heater - 230/240V - 50/60Hz IEC Inlet Print Switch Black 14ga Ground Print Switch to Frame White 14ga Circuit Circuit Breaker Breaker ON/OFF Switch Black 14ga White 14ga WWW.HOTRONIX.COM...

  • Page 14: Replacement Parts List

    HOTRONIX ® Replacement Parts List AIR FUSION IQ ™ ITEM # PART NAME PART # ITEM # PART NAME PART # Air Fitting, Muffler, 1/8" NPT 1-2418 Air Fusion Control Housing 1-2197 Speed Control Muffler 1-2339 Cap, Plastic Black 1/2"...
  • Page 15 Parts Location Guide WWW.HOTRONIX.COM...

  • Page 16: Contact

    HOTRONIX ® CONTACT US AIR FUSION IQ ™ Stahls’ Hotronix ® One Industrial Park Carmichaels, PA 15320 U.S.A. Technical Support 800.727.8520 Speak with a representative 24 hours a day, 7 days a week, 365 days a year. Customer Service 800.727.8520...
