Two sine-wave oscillators modulating each other's phase.
HARMONICS: frequency ratio.
TIMBRE: modulation index.
MORPH: feedback, in the form of operator 2 modulating its own phase (past 12 o'clock, rough!) or
operator 1's phase (before 12 o'clock, chaotic!).
AUX: sub-oscillator.
Note: turn MORPH
to recreate the same sounds as Braids' FBFM. A gentler palette equivalent to Braids'
MORPH at 12 o'clock.
Granular formant oscillator
Simulation of formants and filtered waveforms through the multiplication, addition and synchronization of
segments of sine waves.
HARMONICS: frequency ratio between formant 1 and 2.
TIMBRE: formant frequency.
MORPH: formant width and shape. This controls the shape of the window by which a sum of two
synchronized sine oscillators is multiplied.
simulation of filtered waveforms by windowed sine waves – a recreation of Braids' Z*** models.
AUX:
HARMONICS controls the filter type (peaking, LP, BP, HP), with smooth variation from one response to
another.
Harmonic oscillator
An additive mixture of harmonically-related sine waves.
HARMONICS: number of bumps in the spectrum. Starts with one big bump, and progressively adds
ripples around it.
https://mutable-instruments.net/modules/plaits/manual/
fully CCW to get the same range of sounds as Braids' WTFM. Turn
Mutable Instruments | Plaits
MORPH fully CW
FM is found with
