3/14/2021
Beads
OOPS!
In an older printed version of this manual, in the Patch ideas section, the
referred to as POSITION.
INSTALLATION
Beads requires a
-12V/+12V
must be oriented on the same side as the "Red stripe" marking on the module and on your power distribution
board. The module draws
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This device meets the requirements of the following standards: EN55032, EN55103-2,
EN61000-3-2, EN61000-3-3, EN62311.
BEADS IN A NUTSHELL
https://mutable-instruments.net/modules/beads/manual/
User manual
power supply (2x5 pin connector). The red stripe of the ribbon cable (-12V side)
100mA
from the +12V rail, and
Mutable Instruments | Beads
10mA
from the -12V rail.
TIME
parameter is incorrectly
1/8
Advertisement
Related Manuals for Mutable Instruments Beads
Summary of Contents for Mutable Instruments Beads
- Page 1 3/14/2021 Mutable Instruments | Beads Beads User manual OOPS! In an older printed version of this manual, in the Patch ideas section, the TIME parameter is incorrectly referred to as POSITION. INSTALLATION Beads requires a -12V/+12V power supply (2x5 pin connector). The red stripe of the ribbon cable (-12V side) must be oriented on the same side as the “Red stripe”...
- Page 2 3/14/2021 Mutable Instruments | Beads One way of picturing how Beads operates is to imagine a tape loop, on which incoming audio is continuously recorded. Every time you request a grain to be played (in reaction to a trigger, a button press, periodically, or randomly), a new replay head positions itself along the tape.
- Page 3 10 seconds, the content of the buffer is backed up, and will be restored the next time the module is powered on. Beads will not switch between stereo and mono operation, or change the recording quality, while FREEZE engaged.
- Page 4 3/14/2021 Mutable Instruments | Beads Four parameters control at which buffer position, pitch, and with which duration and envelope the grains are replayed. More precisely, these parameters and their respective modulations are read once, whenever a grain starts, and remain unchanged throughout the duration of the grain. If a parameter then changes, it will only impact the next grain.
-
Page 5: Patch Ideas
3/14/2021 Mutable Instruments | Beads CW) distribution. The random values from the peaky distribution are clustered towards the middle, with extreme values being infrequently generated. PATCH IDEAS Patch a ramp-down LFO, or a decaying linear envelope into the TIME CV input for “scrubbing” the buffer, or a segment of it, at whichever speed the LFO rate or envelope time is set to. - Page 6 8. Audio output. While the recording buffer can be mono or stereo, Beads’ signal processing chain is always stereo. If the R output is left unpatched, both L and R signals are summed together and sent to the L output.
- Page 7 At 12 o’clock, the pitch- shifter is bypassed. Slow random LFOs are internally routed to the attenurandomizers [I]. BEADS AS A GRANULAR WAVETABLE SYNTH When both audio inputs are left unpatched, and at the end of a period of ten seconds, Beads...
-
Page 8: Advanced Topics
WARRANTY This product is covered by Mutable Instruments’ warranty, for one year following the date of manufacture. This warranty covers any defect in the manufacturing of this product. This warranty does not cover any damage or malfunction caused by incorrect use - such as, but not limited to, power cables connected backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
