Installation Guide | PROFIBUS Card
Data request Description
number
6 Power (kW)
7 Power (kVA)
8 Voltage
9 Current
10 Current
11 Current
12 Voltage
13 Voltage
14 Voltage
15 Version
Danfoss A/S © 2018.09
Bits Details
0–11 Power
12–15 Power scale
0=Multiply power by 10 to get W
1=Multiply power by 100 to get W
2=Power (kW)
3=Multiply power by 10 to get kW
0–11 Power
12–15 Power scale
0=Multiply power by 10 to get VA
1=Multiply power by 100 to get VA
2=Power (kVA)
3=Multiply power by 10 to get kVA
0–13 Average rms voltage across all 3 phases
14–15 Reserved
0–13 Phase 1 current (rms)
14–15 Reserved
0–13 Phase 2 current (rms)
14–15 Reserved
0–13 Phase 3 current (rms)
14–15 Reserved
0–13 Phase 1 voltage
14–15 Reserved
0–13 Phase 2 voltage
14–15 Reserved
0–13 Phase 3 voltage
14–15 Reserved
0–7 Software minor version number
8–15 Software major version number
Data Structures
