436CP42UG PARTS & HARDWARE
DESCRIPTION QTY.
Boom section, 1-1/2 x .058 x 59" SBE ......................... 1
Boom section, 1-1/4 x .058 x 42-1/2" SOE .................. 1
Boom section, 1-1/4 x .058 x 46-1/2" SOE .................. 1
Boom section, 1 x .058 x 31" STR ............................... 1
Boom section, 1 x .058 x 59" STR ............................... 1
Boom to mast plate, 4 x .125" angle (M2APT0063) ..... 1
Elements, 3/16" alum. rod x (see dim. sheet) .............. 42
Driven element block assembly ................................... 2
`T' Block assembly (SADE0060) .................................. 1
Balun, RG-6U halfwave length ..................................... 2
Phasing line, RG6-U, 1/4 ............................................. 1
Phasing line, RG6-U 3/4 .............................................. 1
U-bolt and cradle, 2" ..................................................... 2
U-bolt and cradle, 1-1/2" .............................................. 2
Assembly instructions .................................................. 1
IN HARDWARE BAG
Shorting bars, .75 x 1.532 x .250" mach. alum. ........... 4
Button insulators, 3/16" black ...................................... 84
Shaft Retainers, 3/16" ss .............................................. 84
Nut, 5/16-18 ss ............................................................. 8
Lockwasher, 5/16" ss ................................................... 8
Screw, 8-32 x 2" ........................................................... 2
Screw, 8-32 x 1-1/4" panhead ..................................... 3
Screw, 8-32 x 1-3/4" panhead ..................................... 4
Screw, 8-32 x 1-1/2" panhead ..................................... 4
Set screw, 8-32 x 1/4" ss ............................................. 8
Locknut, 8-32 ss ........................................................... 10
Allen wrench, 5/64" ..................................................... 1
Push tube, 3/8 x 3" (for keeper installation) .................. 1
Cable ties, 8" ................................................................ 5
