M2 Antenna Systems 436CP16 Assembly Manual

Advertisement

Quick Links

SPECIFICATIONS:

Model ......................................... 436CP16
Frequency Range ....................... 432 To 440 MHz
*Gain .......................................... 13.3 dBic
Front to back .............................. 15 dB Typical
Beamwidth ............................... 42° Circular
Feed type ................................... Folded Dipole
Feed Impedance. ....................... 50 Ohms Unbalanced
Maximum VSWR ........................ 1.5:1
Input Connector .......................... "N" Female

FEATURES:

The 436CP16 is a light weight, circularly polarized antenna optimized for Low Earth Orbit (LEO) satellite
communications or other applications where a small circular polarized antenna is required. Optimum match and gain are
between 432 & 440 MHz for the satellite band. Rear mounted for easy coaxial cable routing. A preamp can be mounted
close to the antenna for almost no coax loss before the preamp, maximizing your receive performance. Computer design
techniques help keep spurious side lobes low down for optimum signal to noise ratios. This antenna features the same
CNC machined, O-ring and silicone-gel sealed, driven element assemblies common to all M
years of trouble free performance regardless of weather.
M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722
M2 Antenna Systems, Inc.
Model No: 436CP16
*Subtract 2.14 from dBi for dBd
Tel: (559) 432-8873 Fax: (559) 432-3059 Web: www.m2inc.com
©2016 M2 Antenna Systems Incorporated
Power Handling .......................... 1 kW
Boom Length / Dia ...................... 65-3/4" / 1"
Maximum Element Length .......... 13-3/4"
Turning Radius: .......................... 64"
Stacking Distance ....................... 36"
Mast Size .................................... 1-1/2" to 2" Nom.
Wind area / Survival ................... 0.4 Sq. Ft. / 100MPH
Weight / Ship Wt. ........................ 4 Lbs. / 7 Lbs.
2
Yagi antennas. This insures
08/16/16
Rev.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 436CP16 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for M2 Antenna Systems 436CP16

  • Page 1: Specifications

    *Subtract 2.14 from dBi for dBd FEATURES: The 436CP16 is a light weight, circularly polarized antenna optimized for Low Earth Orbit (LEO) satellite communications or other applications where a small circular polarized antenna is required. Optimum match and gain are between 432 &...
  • Page 2 436CP16 DIMENSION SHEET...
  • Page 3 436CP16 ASSEMBLY MANUAL TOOL REQUIRED FOR ASSEMBLY: Screwdriver, 11/32 nut driver or wrench, 7/16” and1/2” socket or end wrenches, measuring tape. 1. Locate boom sections #1 & #2. ASSEMBLING THE HORIZONTAL ELEMENTS 2. Lay out the elements by “H” length and position as shown in the DIMENSION SHEET. Start with the reflector (longest) element.
  • Page 4 436CP16 ASSEMBLY MANUAL 9. INSTALLATION OF THE VERTICAL DRIVEN ELEMENT BLOCK DETERMINES THE CIRCULARITY OF THIS ANTENNA. THE ORIENTATION OF THE BLOCK FOR RHC - RIGHT HAND CIRCULARITY, IS SHOWN ON THE DIMENSION SHEET AND DRAWING AND DESCRIBED BELOW: Viewed from the rear of the boom (rearmost Reflector HORIZONTAL), the VERTICAL Driven Element Block mounts to the RIGHT hand side of the boom with the two Balun connectors oriented to the FRONT.
  • Page 5 436CP16 ASSEMBLY MANUAL 12. The boom to mast plate is at the REAR of the boom. Use two 1" U-bolts and the stainless nuts and lock washers provided. DO NOT OVER TIGHTEN. 2” U-bolts (and stainless steel nuts / lockwashers) are provided for mounting the antenna to your mast or cross boom, other sizes are available upon request.
  • Page 6 436CP16 PARTS & HARDWARE DESCRIPTION QTY. Boom Section #1, 1 x .058 x 36" SOE ........ 1 Boom Section #2, 1 x .058 x 35-1/4" ........1 Elements, 3/16" alum. rod x (see dims.) ......16 Driven Element Assembly ............ 2 Junction Block Assembly (SADE0065) ........
