Barco PreCa 1280i Manual

Rs232-c communication control commands, presentation camera
Hide thumbs Also See for PreCa 1280i:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Network Manual
BARCO PROJECTION
SYSTEMS
PreCa
1280i
R9840700
RS232-C
Communication Control Commands
Date :
Ver. :
02
20.10.00

Advertisement

Table of Contents
loading

Related Manuals for Barco PreCa 1280i

Summary of Contents for Barco PreCa 1280i

  • Page 1 BARCO PROJECTION SYSTEMS PreCa 1280i R9840700 RS232-C Communication Control Commands Date : Ver. : 20.10.00...
  • Page 2 From the windows DOS prompt, enter the Telnet IP address (e.g., Telnet 128.21.160.10) to activate the Telnet client. If the internal server “User ID” of PRECA 1280i is set to “anonymous” under “Network settings” in the Setup menu, logging on is automatic.
  • Page 3 (Note: these are not the same commands that PRECA 1280i supports.) FTP protocol is for transferring files, the PRECA 1280i enables you to exchange ASCII commands by issuing the expansion commands. Input “ftp>literal excm s_ulon”. The lighting on as Telnet.
  • Page 4 The ASCII expansion command system adds one space (ASCII code, “CR” (0DH) and “LF” (0AH)). When the PRECA 1280i issues the command: If the command is established, a number code from 200 and over, and the corresponding message are displayed.
  • Page 5 (When you develop new software, the CR/LF command system is recommended.) ASCII command ASCII command When the command is issued to PRECA 1280i: If the command is established, “ACK” (06H) is displayed. If the command is executed correctly, “NAK” (15H) is displayed.
  • Page 6 RAMIBOX<DIR> CardIBox<DIR> The RAMIBOX is a virtual directory within PRECA 1280i, and the CardIBox is a directory on a PC card. (Image data is saved in this directory.) The CardIBox is displayed using the List command even if a PC card is not inserted.

  • Page 7: Table Of Contents

    List of Commands Command Function Commands for basic operation m_ZMW t Move the Zoom (ring) to Wide side m_ZMT t Move the Zoom (ring) to Tele side m_FCN t Move the Focus (ring) to Near side m_FCF t Move the Focus (ring) to Far side m_AF Auto-focus s_AEON...
  • Page 8 s_GNR n Set the red gain s_GNG Set the green gain s_GNB n Set the blue gain s_SP n Set level of image sharpness Commands for operating files t_FB Set file type to Bitmap format t_FJ Set file type to JPEG format t_JQ n Set compression rate of JPEG image file Set reading image size to 320∗240...

  • Page 9: Move The Zoom (Ring) To Wide Side

    Commands for Basic Activations Command: m_ZMV t Move the zoom (ring) to Wide side m_ZMT t Move the zoom (ring) to Tele side Functions: These commands control the zoom activation. The zoom motor is activated for the time specified, where t = time (msec). The specified time has a different movement, depending on the position of the zoom ring.

  • Page 10: Auto-Focus

    Command: m_AF Auto-focus Functions: This command executes the auto-focus function of this unit, for automatic focusing on the subject. Note: If you select zoom or auto-focus when the auto-focus is already selected, the auto-focus will stop, and then either zoom will activate or auto-focus will re- activate.

  • Page 11: Open Iris

    Command: s_IR n Auto-IRIS compensation mode Function: This command sets a compensation value for the IRIS when the IRIS function of the unit is set to auto-mode. The compensation value, “n” can be selected from –3 to +7. (Note that +1 is not the same as +1EV for a camera.) –3 means the iris is closed completely, and +3 means the iris is opened fully.

  • Page 12: Overhead Lighting On

    Commands for Setting Screen Command: s_ULON Overhead lighting on s_ULOFF Overhead lighting off s_BLON Base lighting on s_BLOFF Base lighting off s_LOFF Overhead and base lighting off Function: These commands control on/off of the fluorescent lamp. The overhead fluorescent lamp and base light cannot be lit at the same time (i.e., while one is lit, the other is off).

  • Page 13: Set Tv Output To Ntsc

    Command: s_NTSC Set TV output to NTSC. s_PAL Set TV output to PAL. s_TVOFF Stop TV output. Function: These commands set the output mode of the TV (Sub-screen). Setting this command will not change the CRT output (Main screen). When you stop output with the “s_TVOFF“ command, the restoration of output is made using the “s_NTSC”...

  • Page 14: Electronic Zoom

    Command: s_EZ n Electronic zoom Function: This command sets the magnification of the electronic zoom of the CRT output (Main screen). You can change the magnification of the electronic zoom function where “n” represents the setting value. “n = 100” means magnification. And “n = 1600” is the maximum setting value. A setting of 100 or less will be displayed as magnification.

  • Page 15: Change Of Gradation Features

    Commands for Setting Screen Command: m_WB White balance (metering exposure) Function: This command adjusts the white balance for the current environment. measures the metering exposure and compensates the white balance/shift against the subject. Command: s_TONE Change of gradation features Function: This command changes the tone setting where “n”...

  • Page 16: Set The Gain

    Command: s_GAIN Set the gain of an image Function: This command compensates the gain value of an image, where “n” represents the value. The setting can be selected from 20 to 260. A 100 is set at magnification (Gain 1). As “s_GAIN”...

  • Page 17: Set File Type To Bitmap Format

    Commands for Operating Files Command: s_SP n Set the sharpness level. Function: This command sets the sharpness level of an image, where “n” represents a setting value from 0 to 5. The setting 0 means sharpness off, with each setting through 5 representing increased sharpness, 5 being the sharpest.
  • Page 18 Command: t_JQ n Set data compression rate of JPEG Function: This command sets the data compression rate for saving JPEG image files. The setting value is from “n = 50” through “n = 100”. The setting values of this unit are: Fine = 100, Normal = 95, Basic = 90, Draft = 85.
  • Page 19 Commands for Saving Activations Command: r_DT Transfer image files to an FTP server. r_DS Save image files to an FTP server. Function: These commands save image files. The File format of image data is specified in either the Setup menu or with the “t_FJ / s_FB”...

  • Page 20: Return Crt Output To Ccd Image

    Commands for Display Activations Command: d_FIL/directory name Displays image files of the PC card on CRT. /image file name (“ ” can substitute for “/”) Function: The command specifies a directory and image file name, and displays its image on the CRT output (Main screen). Possible file formats are BITMAP and JPEG formats.
  • Page 21 Communications Related Commands Command: w_LCA str Registration of Location displayed by WEB r_LCA Reading of Location displayed by WEB Function: These commands register/read a location. These commands’ character strings are displayed for the Location on the WEB. “str” is an ASCII character string using maximum of 32 characters. Small letters are converted into capital letters (i.e., not case sensitive).
  • Page 22 Commands for Others Command: s_RSOK Set display of RS232C to ASCII character string s_RSACK Set display of RS232C to 1Byte code Function: These commands display the ASCII character strings of “OK CR/LF” and “NG CR/LF” when this unit enables reception of 1Byte commands from the RS232C, including ACK (06H), NAK (15H).

  • Page 23: Display Of Product Name And Version

    Command: uname Display of product name and version. Function: Product name of “Hyper Imager” is displayed. For version information, the same contents are obtained as when the “v_VER” command is executed. Command: v_VER Display of version Function: This command reads and displays version information. The same contents are displayed as when the “uname”...
