Marshall Electronics V-1070CCIR Manual

V-1070 / V-1070CCIR 1/2" HIGH RESOLUTION B/W CAMERA
1. SPECIFICATION
TV System
Image Device
Image Area
CCD Total Pixels
Frequency --- Horizontal
Frequency --- Vertical
Scanning System
SYNC System
External SYNC
Minimum illumination
S / N Ratio
Resolution
BLC Function
Gamma Correction
Gain Control
Electronic Shutter
Video Output
Video Connector
Auto-iris Output
Auto-iris Connector
Power Voltage
Power Consumption
Power Connector
Lens Mount
Operating Humidity
Operating Temperature
Weight
Dimensions
＊ S p e c i f i c a t i o n ,
V-1070 - V-1070CCIR Data Sheet / Manual
20608 Madrona Avenue, Torrance, CA 90503 USA
811 (H) X 508 (V)
525 Lines , 60 Fields / sec
Internal / External SYNC
Composite Video Signal or Composite SYNC Signal (500 mv p-p TTL)
0.02 Lux at F1.2
Better than 48 dB
600 TV Lines Horizontal
OFF / (ON)
0.45 / (1) / (0.2)
AUTO , 4dB ~ 32dB / (MANU)
10-Seg. Rol-SW (OFF / FIX : 8 step / AES : 1/60 or 1/50 ~ 1/100,000 sec)
Composite 1.0V P-P at 75 ohm
8P mini Dim-Plug
AI / (DD)
4 - Pole Plug
DC 12V ± 10 %
250mA / 3 W
8P mini Din-Plug
C / CS
Within 85 % RH
-10 ℃ 50 ℃
-
300 g Without Lens
42 mm (W) X 64 mm (H) X 98 mm (D)
a p p e a r a n c e
V-1070
1/2 - inch CCD Image Sensor
7.95 mm X 6.45 mm
15.734 K Hz
60 Hz
m a y c h a n g e
V-1070CCIR
795 (H) X 596 (V)
15.625 K Hz
50 Hz
625 Lines , 50 Fields / sec
w i t h o u t n o t i c e .
1
