Marshall Electronics V-C310-HDSDI User Manual

Features
. Optical 10X zoom installed (4.5-45mm)
. A variety of resolutions supported
(1920X1080 30P/60i, 1280X720 60p)
. HD-SDI SMPTE 292M Standard
. Uncompressed transmission for zero signal delay
. Video transmission up to 100M
(5C-HFBT coaxial cable)
. Data control by RS-232
. Easy coaxial cable installation
Remote Control
V-C310-HDSDI Manual
Marshall Electronics
V-C310-HDSDI
Day&Night
OSD
. Distance : 10M
. When RC is on : LED will blink
Cancel setup value and
Exit Setup mode
Brightness
User Manual
2.2
White Balance DC 12V Megapixel
1/2.5" 10X
WDR CMOS 4.5-45mm
Day&Night White Balance
OSD WDR
Caution
. Adapter : DC 12V 1A
. Do not disassemble
. Camera lens needs to be protected from impact
. If problems are found, please contact us
for installation help
Move to Up, Down, Left, Right
Zoom In/Out
2.2
DC 12V Megapixel
10X
1/2.5"
CMOS 4.5-45mm
Enter and function key
Resolution
1
