MXL017/65Q & 85Q
Installation Instructions
UK contact:
Helpline:
+44 (0)1553 811000
Email:
support@maxview.co.uk
Web:
www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111340 Iss 1
Target, SKY Q™ Variant
Advertisement
Table of Contents
Related Manuals for Maxview TARGET MXL017/65Q
Summary of Contents for Maxview TARGET MXL017/65Q
-
Page 1: Installation Instructions
MXL017/65Q & 85Q Target, SKY Q™ Variant Installation Instructions UK contact: Helpline: +44 (0)1553 811000 Email: support@maxview.co.uk Web: www.maxview.co.uk Maxview reserve the right to change specifications without prior notice 9111340 Iss 1... - Page 2 1. Product Installation Schematic Layout Sky Q™ Adaptor Input from Quad LNB Typical installation Maxview Control Box Sky Q™ Adaptor 240V 3 pin plug Sky Q ™ DVBT-S Receiver Ensure the Maxview Control Box is installed before the SKY Q™ Adaptor.
- Page 3 2. Power Supply You will need a 20v DC regulated power supply to power the Adaptor. The unit is supplied with a UK mains powered 20v DC PSU. 3. Location Decide the location to site the Adaptor. Please ensure you mount the Adaptor correctly and securely using the screw fixings holes. Ensure you can route the coaxial and power to the Adaptor in your chosen location.
- Page 4 It is the responsibility of the end user to understand the contractual agreement between themselves and SKY Q™ and any limitations of equipment this may have. In no event shall Maxview be liable for any indirect, incidental, or consequential damages pertaining to this document.
