- Page 1 MXL003/65Q/85Q Seeker Sky Q™ & Auto Skew Installation & operating instructions UK contact: Helpline: +44 (0)1553 811000 Email: support@maxview.co.uk Web: www.maxview.co.uk Maxview reserve the right to change specifications without prior notice 9111403SKYQ Iss 3...
-
Page 2: Table Of Contents
All instructions and models are subject to change. In accordance with policy of progressive product, the company reserve the right to alter specifications. Copyright© these instructions are the sole property of Maxview Ltd and may not be reproduced. Please keep these instructions safe for future reference. -
Page 3: Safety Precautions
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Maxview declines all responsibility in the event of incident or accident if they are due to a non observation of the installation instructions or the way the product is used. -
Page 4: Application Example
Application example: A. Antenna The Antenna is mounted to the roof. It uses electric motors to scan for satellite signals. It has 3 cable connections; 1 for controlling the motors and 2 satellites signal cables from the Twin LNB. B. Control Box The Control Box requires wired connections for power, antenna control and satellite signal. -
Page 5: Connections & Features
> Cable Clips > Flylead (for connection to satellite receiver) > M6 Button Head Screw x 4 > M6 Locking Nut *Maxview recommends the following adhesives: > 6mm Plastic Washer > Sikaflex®-512 Caravan > Cable Entry Plate > Geocel® Geobond HM >... -
Page 6: Selecting An Installation Location
> Check for electrical cables beneath screw fixing points. > Check Antenna Unit cables will reach Control Box (Maxview can supply extended cables). > Do not allow the dish to overhang the edge of the vehicle > Clearance around antenna system when in use is shown with reference... -
Page 7: Attaching Antenna Mount Plate
Attaching Antenna Mount Plate & LNB Park Plate: Remove antenna unit from wooden transit packaging Remove mounting plate from Antenna Unit by removing 6 x M6 nuts using 10mm spanner Clean roof, Mounting Plate and LNB Park Plate in accordance with adhesive manufacturer’s guidelines Mark a centre line for the antenna making sure dish will not overhang vehicle Align notches on plate with centre line Mark the position of 6 screw fixing holes... -
Page 8: Electrical Installation
Electrical installation: Whilst the adhesive is curing prepare the electrical connections for the Control Box. The Control Box requires a permanent 12V supply and a secondary 12V supply that provides power when the engine of the vehicle is running. Note: the brake light circuit is not suitable. It is recommended to create a new circuit direct to the battery using a minimum cable cross sectional area of 2.5mm 2 and an inline fuse of 5A. -
Page 9: Attaching Antenna Unit To
Application example: Use extra Cable Entry Plate to route 2nd Sat feed to a different location. Available to order from Maxview MXL018 Direction of travel (front of vehicle) Note: To prevent trip hazards it is recommended that cables are concealed in PVCu conduit (not supplied) where access is required to the roof of the vehicle. -
Page 10: Installing Control Box
Installing Cable Entry Cover Cable Plan your installation carefully Drill a 32mm ø hole in roof 3. Prepare surface for adhesion Hole location 4. Apply sealant as shown in A,B,C tabs Top hat (we recommend Sikaflex-512 Caravan)* 5. Position top hat 6. - Page 11 Installing Control Panel Choose most suitable method of communication between Control Panel and Control Box. Wireless mode: Install batteries into Control Panel in accordance with instructions on page 12. Turn Control Box and Control Panel on. Pair Control Box and Panel together see page 13. Choose suitable location for Control Panel –...
-
Page 12: Connection Diagram
Connection diagram: SAT 1 (Cable marked V) SAT 2 (Cable marked H) SAT 2 IN Sky Q™ Receiver Splitter 5A Fuse Not required Ignition Attach Satellite Dish to Antenna Unit Ensure Antenna Unit is free from obstacles. Press installation button on reverse of Control Box to elevate antenna. -
Page 13: Installing Batteries
Testing Antenna Unit: Position the vehicle so that there is an unobstructed view of the southern sky. Follow instructions on page 15 to search for a satellite. Caution: Before driving vehicle on a highway ensure adhesive has cured. Check all fasteners are secure. Installing batteries: Remove the battery door and insert 2 AA (LR6) batteries as shown. -
Page 14: Pairing Control Panel And Control Box
Pairing Control Panel and Control Box: Every Control Panel made by Maxview contains a unique electronic identification number to prevent interference between neighbouring Seeker satellite systems. When the Control Panel and Control Box are not paired the Control Panel displays RF ERROR. -
Page 15: Starting Search Mode
Starting search mode: Turn on Control Box and Control Panel If Control Panel is in sleep mode displaying clock/temp press any button to wake panel Using the Change Satellite UP/DOWN Buttons select a satellite* Press Antenna Search button Note: If the search button is not pressed within 3 seconds of selecting a new satellite the seeker will revert back to the last acquired satellite. -
Page 16: Ignition Mode
When power is restored to the system the antenna will automatically lower into the park position. Software Update: To keep your Seeker up to date with the latest satellites Maxview has incorporated a USB port on the front of the Control Box. The Seeker has the ability to update its satellite data and its operational software from a simple USB flash memory stick. -
Page 17: Skew Adjustment
If you have any further questions regarding manual or automatic skew adjustment, please contact Maxview Customer Services on +44 (0)1553 811000 or visit www.maxview.co.uk. Astra 2 - 28.2° Astra 1 - 19.2°... -
Page 18: Software Update
AZ ERROR Movement of motor not detected therefore check cable EL ERROR connections and reset power If problem is not resolved contact Maxview customer service. NO SAT FOUND Check antenna has no obstructions to the southern sky Check LNB cable connection Weak signal area –... -
Page 19: Guarantee
A guarantee authorisation must be obtained from Maxview prior to work commencing. c) Maxview is responsible for the cost of a replacement part if the original part is determined to be defective under the terms of the guarantee. -
Page 20: Specifications
It is the responsibility of the end user to understand the contractual agreement between themselves and SKY Q™ and any limitations of equipment this may have. In no event shall Maxview be liable for any indirect, incidental, or consequential damages pertaining to this document.
