Simplicity at its best
Additional set up & user instructions
Please refer to the instructions in this booklet to set up and use
your Precision I.D System.
These should be read in conjunction with the
'Precision Set Up and User Manual'
UK contact:
Helpline:
+44 (0)1553 811000
Email:
support@maxview.co.uk
Web:
www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
MXL019INS Iss 2
For models:
MXL019/55
MXL019/65TWIN
MXL019/55TWIN
MXL019/75
MXL019/65
MXL019/75TWIN
Advertisement
Table of Contents
Related Manuals for Maxview Precision I.D MXL019/55
Summary of Contents for Maxview Precision I.D MXL019/55
- Page 1 These should be read in conjunction with the ‘Precision Set Up and User Manual’ For models: UK contact: MXL019/55 MXL019/65TWIN Helpline: +44 (0)1553 811000 MXL019/55TWIN MXL019/75 Email: support@maxview.co.uk MXL019/65 MXL019/75TWIN Web: www.maxview.co.uk Maxview reserve the right to change specifications without prior notice MXL019INS Iss 2...
- Page 2 System set up Set up the Precison I.D system as per the ‘Precision’ instructions To use the ‘Sat Found LED’ function you must install the inline Sat I.D Audio Module as shown on the following pages Pack contents Audio Sat ID Module 1m ‘F’...
-
Page 3: User Instructions
Set up example Inside vehicle Outside your vehicle Your Precision I.D Inline SAT I.D Module RCA male to male Headphone ‘F’ Flylead socket TV OUT LNB IN AUDIO OUT SAT Receiver If you do not have an Audio Out (RCA) on your receiver you can use headphone socket on TV. Note: You will need to disconnect the headphone socket once satellite has be found TV will be muted. - Page 4 Troubleshooting and FAQ’s: 1. I don’t want to use the Sat Finder, can I turn it off? Turn the knob fully to the left. Keeping it in-line doesn’t affect your signal quality and uses very little power. 2. My Sat Finder LED lights (red) increase but I have no picture OR Sat Found LED does not light - You may have located a different satellite to the one your receiver is set to.
