- Page 1 MXL003 Seeker Wireless Installation & Operation Instruction Manual 9111403 Iss 1...
-
Page 2: Useful Information
Useful Information Date of Purchase Retailer Installer Serial Number... -
Page 3: Table Of Contents
Contents Warranty ....................................4 Safety Precautions ................................. 5 Introduction .................................... 6 Proper Use & Operation ..............................6 Connections & Features ................................ 8 Control Panel ..................................8 Control Box ..................................9 Antenna Unit ..................................9 Installation ................................... 10 Required Tools & Equipment (not supplied) ........................10 Product Contents ................................ -
Page 4: Warranty
Should any trouble develop during the warranty period please contact Maxview before the warranty period expires. If you do experience a problem with the product contact Maxview Customer Services on (01553) 811000 or email cust_serv@maxview.co.uk. Please make sure you have the following ready when you call: Your name •... -
Page 5: Safety Precautions
Do not operate the Seeker Wireless with snow or ice on the antenna. • Servicing If in the event that you do experience a problem with the system call Maxview • Customer Service +44 (0)1553 811000. Any inspection or repair must be carried out by Maxview or an appointed •... -
Page 6: Introduction
All instructions and models are subject to change. In accordance with policy of progressive product, the company reserve the right to alter specifications. Copyright© these instructions are the sole property of Maxview Ltd and may not be reproduced. Please keep these instructions safe for future reference. -
Page 7: Control Box
Antenna The Antenna is mounted to the roof. It uses electric motors to scan for satellite signals. It has 3 cable connections; 1 for controlling the motors and 2 satellites signal cables from the Twin LNB. Control Box The Control Box requires wired connections for power, antenna control and satellite signal. -
Page 8: Connections & Features
Connections & Features Control Panel 1. Antenna Search button 2. Antenna Park button 3. Antenna position icon 4. Battery status icon 5. Change Satellite Up/Down buttons 6. Wireless mode icon 7. Cable mode icon 8. ON/OFF switch 9. Battery door 10. -
Page 9: Control Box
Control Box 1. Fuse 7. LNB IN 2. Power Switch 8. LNB OUT 3. Power LED 9. Antenna Connectors 4. Sync Button 10. RJ25 Panel Connector 5. Status LED 11. Installation Button 6. USB update port 12. Power input Antenna Unit 1. -
Page 10: Installation
Conduit (recommend method for securing cables) • Automotive 2.5mm cable • Electrical connector block • F-F Fly lead ( for connection to satellite receiver) • *Maxview recommends the following adhesives: ® Sikaflex -512 Caravan • ® Geocel Geobond HM •... -
Page 11: Selecting An Installation Location
Check for obstructions such as roof lights and vents. • Check for electrical cables beneath screw fixing points. • Check Antenna Unit cables will reach Control Box (Maxview can supply extended • cables). Do not allow the dish to overhang the edge of the vehicle •... -
Page 12: Attaching Antenna Mount Plate & Lnb Park Plate
Attaching Antenna Mount Plate & LNB Park Plate 1. Remove antenna unit from wooden transit packaging. 2. Remove mounting plate from Antenna Unit by removing 6 x M6 nuts using 10mm spanner. 3. Clean roof, Mounting Plate and LNB Park Plate in accordance with adhesive manufacturer’s guidelines. -
Page 13: Electrical Connections
Electrical Connections Whilst the adhesive is curing prepare the electrical connections for the Whilst the adhesive is curing prepare the electrical connections for the Control B Control Box. The Control Box requires a permanent 12v supply and a secondary 12v supply that provides Control Box requires a permanent 12v supply and a secondary 12v supply that provides Control Box requires a permanent 12v supply and a secondary 12v supply that provides power when the engine of the vehicle is running. - Page 14 Caravans Power can be taken directly from the leisure battery on the caravan. The ignition cable should be connected to the ignition key circuit which can be traced using the charts below. The caravan will either be fitted with the 13 Pin Euro Connector or have two 7/8 Pin connectors.
-
Page 15: Attach Antenna Unit To Mounting Plate
Attach Antenna Unit to Mounting Plate Carefully lower the antenna unit onto the Mounting Plate and re-attach the M6 Nuts and Washers that were previously removed. Caution Replace Nylon locking nuts if they have been removed more than twice. The locking action of the Nylon becomes less effective if repeatedly assembled and disassembled. -
Page 16: Installing Control Box
Installing Control Box Having previously chosen a suitable location 1. Clip the mounting brackets onto the Control Box. 2. Place Control Box on the horizontal or vertical surface and mark the 4 holes. 3. Depending on material drill a pilot hole or use a bradawl. 4. - Page 17 Connection Diagram Antenna Cable Satellite Cable Satellite Cable IGNITION Optional Cable for Control Panel 5A FUSE & Satellite Receiver...
-
Page 18: Installing Control Panel
Installing Control Panel Choose most suitable method of communication between Control Panel and Control Box. Wireless Mode 1. Install batteries into Control Panel in accordance with instructions on page 20. 2. Turn Control Box and Control Panel on. 3. Pair Control Box and Panel together see page 21. 4. -
Page 19: Attach Satellite Dish To Antenna Unit
Attach Satellite Dish to Antenna Unit 1. Ensure Antenna Unit is free from obstacles. 2. Press installation button on reverse of Control Box to elevate antenna. Once elevated turn off power to Control Box and remove fuse. 3. Fix satellite dish to Antenna Arm using M6 Button Head Screws, M6 Nuts and 6mm Plastic Washers. -
Page 20: Operation Guide
Operation Guide Installing Batteries Remove the battery door and insert 2 AA (LR6) batteries as shown. Take care to observe the correct polarity and to use good quality sealed alkaline batteries. Caution Incorrect installation may cause battery leakage and corrosion, resulting in damage to •... -
Page 21: Pairing Control Panel And Control Box
Pairing Control Panel and Control Box Every Control Panel made by Maxview contains a unique electronic identification number to prevent interference between neighbouring Seeker satellite systems. When the Control Panel and Control Box are not paired the Control Panel displays RF ERROR. -
Page 22: Finding A Satellite
Finding a Satellite Location & Set-up Before starting check there is a clear line of sight to the southern sky. All television broadcasting satellites have a geostationary orbit which means their location is fixed above the earth’s equator. Satellites also have a limited range of transmission so use the Zone maps included in the appendix to check your location is suitable for reception. -
Page 23: Pause Function
Note: Search time is dependent on the change in elevation from last location. The Seeker will start the search routine from the last known elevation angle of the antenna. This greatly reduces the search time which will typically be less than 1 minute. The first search from the factory set position may take as much as 15 minutes. -
Page 24: Ignition Mode
Ignition Mode The ignition mode is a safety feature that automatically lowers the antenna and prevents accidental operation whilst travelling. When the Seeker has detected an active ignition circuit in the vehicle the Control Panel will display ‘IGNITION’. In this mode the antenna is automatically lowered and the Control Panel function is disabled. -
Page 25: Skew Adjustment
Skew Adjustment Skew adjustment is required when signal strength is weak at the limit of a given satellites’ reception area. It involves adjusting the angle of the LNB on the roof mounted antenna unit. ASTRA 28.2... - Page 26 ASTRA 19.2 Caution Follow general safety advice on page 5 when adjusting Antenna Unit.
-
Page 27: Software Update
Software Update To keep your Seeker up to date with the latest satellites Maxview has incorporated a USB port on the front of the Control Box. The Seeker has the ability to update its satellite data and its operational software from a simple USB flash memory stick. -
Page 28: Fault Finding
AZ ERROR Movement of motor not detected therefore check cable connections and reset power. EL ERROR If problem is not resolved contact Maxview customer service. NO SAT FOUND Check antenna has no obstructions to the southern sky Check LNB cable connection Weak signal area –... -
Page 29: Specification
Specification MXL003/65 MXL003/85 Antenna Gain 36.0dB 38.1dB LNB Outputs Wireless Frequency 868.3 MHz Wireless range 10 m Battery type 2 x AA LR6 Alkaline Sealed Fuse 3A Mini Blade Automotive Dimensions Antenna Height (min) 167mm 167mm Antenna Height (max) 960mm... -
Page 30: Ce Declaration Of Conformity
The Seeker Wireless Satellite Antenna has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC. The wireless operation has been designed in accordance with CEPT-70.03. Company Address: Maxview Ltd Common Lane Setchey Kings Lynn Norfolk... -
Page 31: Reception Maps
Reception Maps ASTRA 28.2E 2A/B North Beam 2A/B South Beam ASTRA 2D... -
Page 32: Astra 19.2E
ASTRA 19.2E 1KR 1L & 1M HOTBIRD 13.0E... -
Page 33: Astra 23.5E
ASTRA 23.5E...
