Technical Specifications - APV PS 800 M1 Translation Of The Original Operating Manual

34
Quality for Professionals
9

Technical Specifications

Designation:
Hopper content:
Dimensions (W x H x D):
Weight:
Max. spreading width:
Power supply:
Hydraulic supply with HG
Max. pressure:
Max. oil quantity:
Weight:
Length of the hydraulic hoses:
Dimensions (L x W x H):
Hole pattern for the installation holes on the PS 800 M1:
Fig.: 39
The contact area must have a minimum dimension of 560 x 800 mm!
PS 800 M1
839 litres
1050 x 1270 x 1700 mm
250 kg
12 m
12 V, 25 A
150 bar
38 l/min
40 kg
Tank line 6 m
Supply line for the motor 6 m
Pressure line 0.75 m
Return line 0.75 m
760 x 660 x 270 mm
Units in mm
