Equipped with AEM
Dryflow™ Filter
No Oil Required!
INSTALLATION INSTRUCTIONS
PART NUMBER: 22-436
2004-2005 MITSUBISHI Lancer Ralliart 2.4L
C.A.R.B. E.O. D-392-28
* NOTE: Items with asterisks are legal only for racing vehicles, not applicable
nor intended for use on emissions controlled street or highway vehicles.
AEM Induction System
1 (800) 992-3000
WWW: http://www.aemintakes.com
Advertisement
Related Manuals for AEM 22-436
Summary of Contents for AEM 22-436
- Page 1 Equipped with AEM Dryflow™ Filter No Oil Required! INSTALLATION INSTRUCTIONS PART NUMBER: 22-436 2004-2005 MITSUBISHI Lancer Ralliart 2.4L C.A.R.B. E.O. D-392-28 * NOTE: Items with asterisks are legal only for racing vehicles, not applicable nor intended for use on emissions controlled street or highway vehicles.
- Page 2 PARTS LIST: 22-436 Quantity Part Number Description 2-4361 Intake Pipe 21-201 2.5x5“ Air Filter 20-436 Air Duct Support Bracket 1-2038 Bolt, Hex/Flange M6 X 20 559999 6mm Flat Washer 5-257 2.5/2.75 Hose Adapter 103-BLO-4420 #44 Hose Clamp 103-BLO-4020 #40 Hose Clamp 1-2028 MAF Bolts 8-32 x 1/2"...
- Page 3 Read and understand these instructions BEFORE attempting to install this product. Failure to follow installation instructions and not using the provided hardware may damage the intake tube, throttle body and engine. 1. Preparing Vehicle a. Make sure vehicle is parked on level surface. b.
- Page 4 e) Unclip the Mass Air Flow (MAF) sesnor wiring f) Unscrew the Inlet tube from the throttle body and harness from the air filter housing. pull the inlet tube off the throttle body. h) Remove the two bolts securing the stock air filter g) Unplug the MAF sensor from the engine harness.
- Page 5 Bolt Bracket ® b) Check to see that the inside of the AEM intake a) Use the supplied zip-tie to secure the throttle cable inlet pipe and air filter are clean and free from any to the main wiring harness. Remove the bolt securing foreign objects and/or obstructions.
- Page 6 2b. Use the stock plastic rivets as shown. Step 3f. j) Check fitment around the entire intake. Tighten the ® i) Install the supplied AEM sticker onto the air duct as hose clamps at the throttle body and silicone coupling. shown.
- Page 7 Use AEM Dryflow cleaning kit part # 21-110. b. Use aluminum polish to clean your polished AEM intake tube. c. Use window cleaner to clean your powder coated AEM intake tube. (NOTE: DO NOT USE aluminum polish on powder coated AEM intake tubes)
- Page 8 AEM Air Intake System Warranty Policy ® warrants that its intake systems will last for the life of your vehicle. AEM will not honor this warranty due to mechanical damage (i.e. improper installation or fitment), damage from misuse, accidents or flying debris. AEM will not warrant its powder coating if the finish has been cleaned with a hydrocarbon-based solvent.
