- Page 1 INSTALLATION INSTRUCTIONS PART NUMBER 26-3000C (Gun Metal Grey Finish) 2015 Subaru WRX FA20 (2.0L Turbo)
- Page 3 Read and understand these instructions BEFORE attempting to install this product. Failure to follow installation instructions and not using the provided hardware may damage the kit com- ponents and engine. Tools Needed: 1. Preparing Vehicle Flat Screw Driver 12” Socket Extension a.
- Page 4 Install the 2.75” coupler onto the intercooler inlet b. Remove the O-ring from the factory charge pipe and with its corresponding hose clamps. Do not tighten. install into your new AEM charge pipe with care to orient the tab in its corresponding groove.
- Page 5 Install one of the bolts removed in step 2c loosely into d. Lower your new AEM charge pipe into position and install beginning with the top end at the intercooler and the top-rear flange location on the turbocharger. slide lower end into position to install the other flange (d.
- Page 6 If you are retaining the factory valve or wanting to recir- culate with an aftermarket valve, please purchase AEM’s 26-3000RK recirculation kit. Final Product Installation. Shown with aftermarket valve j.
- Page 7 The powder coating should ® only be cleaned with a mild soap and water solution. Proof of purchase of both the vehicle and AEM intake system is required for redemption of a warranty claim.
