Summary of Contents for AEM 21-831C
- Page 1 ® Equipped with AEM Dryflow™ Filter No Oil Required! INSTALLATION INSTRUCTIONS PART NUMBER 21-831C (GUN METAL GRAY FINISH) 2017 SUBARU FORESTER 2.5L...
- Page 2 ITEM NO. PART NUMBER DESCRIPTION QTY. 21-2027DK Element; 2 3/4” flange 5 1/2” B, 4 3/4 L 2-1592-1C INTAKE TUBE; 2.75" OD X 49", 4" BR; 21-808 20-8606 HEAT SHIELD, SUBARU FORESTER 2017 2.5L, TB/PC 08185 Hose; 2-3/4" ID X 2-1/2" L Hump Reinforced 5-5008 Hose;...
- Page 3 Read and understand these instructions BEFORE attempting to install this product. Failure to follow installation instructions and not using the provided hardware may damage the intake tube, throttle body and engine. If you need any assistance please call1-800-858-3333 to speak with a representative in our Customer Service Center before returning the product.
- Page 4 e. Loosen the hose clamp securing the factory intake to f. Unlatch the air box lid and remove the air box lid and intake resonator assembly out of the engine bay. the throttle body. g. Remove the two nuts and the bolt securing the air h.
- Page 5 When installing the intake system, do not completely tighten the hose clamps or mounting hardware until instructed to do so. a. Install the MAF sensor into the AEM intake tube using b. Attach the provided hose and hose fitting to the in- the provided hardware.
- Page 6 Install the intake tube as shown, sliding the bracket f. Install the AEM DryFlow filter using the provided hose below the washer on the rubber mount. Do not fully clamp onto the intake tube. tighten the nut to allow some movement during installa- tion.
- Page 7 5. Service and Maintenance a. AEM Induction Systems requires cleaning the intake system’s air filter element every 100,000 miles. When used in dusty or off-road environments, our filters will require cleaning more often. We recommend that you visually inspect your filter once every 25,000 miles to determine if the screen is still visible.
- Page 8 The powder coating should ® only be cleaned with a mild soap and water solution. Proof of purchase of both the vehicle and AEM intake system is required for redemption of a warranty claim.
