Thank you for purchasing the AQ7277B Remote OTDR.
This product is an OTDR module, designed to be integrated into a remote fiber test system.
This user's manual explains the handling precautions, specifications, and connection procedures of the
AQ7277B Remote OTDR for users that are involved in remote fiber test.
For correct operation, please read this manual thoroughly before use.
The AQ7277B comes with the following manuals. Please keep them in a safe place.
Manual Title
AQ7277B Remote OTDR User's Manual
AQ7277B Remote OTDR User's Manual
* The "-EN" in the manual number is the language code.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document No.
PIM 113-01Z2
The following manual is a related manual that is downloaded with the remote controller for the AQ7277B
available at the YOKOGAWA website.
Manual Title
Remote Controller for the AQ7277B
Remote OTDR Configuring Network
Settings and Updating the Firmware
AQ7277B OTDR Communication
Interface User's Manual
You can download the remote controller for the AQ7277B (Yokogawa OTDR Remote Controller) and the manual
from the following webpage.
https://tmi.yokogawa.com/library/
Trademarks
• Microsoft,Windows,Windows 7,Windows 8 and Windows 8.1 are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other countries.
• Adobe and Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
• In this manual, the ® and TM symbols do not accompany their respective registered trademark or trademark
names.
• Other company and product names are registered trademarks or trademarks of their respective holders.
Revisions
• 1st Edition: September 2016
• 2nd Edition: November 2016
• 3rd Edition: October 2017
• 4th Edition: March 2018
Model AQ7277B Remote OTDR
Manual No.
IM AQ7277B-01EN
IM AQ7277B-92Z1
Description
List of worldwide contacts
Manual No.
IM AQ7277B-61EN
IM AQ7277B-17EN
4th Edition: March 2018 (YMI)
All Rights Reserved, Copyright © 2016 Yokogawa Test & Measurement Corporation
Printed in Japan
Description
This manual.
A manual for China.
Description
This manual explains how to use the remote
controller for configuring the AQ7277B.
Explains the features related to using communication
commands to control the AQ7277B..
IM AQ7277B-01EN 1/12
4th Edition

Advertisement

Table of Contents
loading

Related Manuals for YOKOGAWA AQ7277B

Summary of Contents for YOKOGAWA AQ7277B

  • Page 1 Contact information of Yokogawa offices worldwide is provided on the following sheet. Document No. Description PIM 113-01Z2 List of worldwide contacts The following manual is a related manual that is downloaded with the remote controller for the AQ7277B available at the YOKOGAWA website. Manual Title Manual No. Description...

  • Page 2: Checking The Package Contents

    List of worldwide contacts Remote Controller for the AQ7277B Remote OTDR A free software for configuring the Remote OTDR. You can download the remote controller for the AQ7277B (Yokogawa OTDR Remote Controller) from the following webpage. https://tmi.yokogawa.com/library/ Conventions Used in This Manual The notes and cautions in this manual are categorized using the following symbols.

  • Page 3: Safety Precautions

    YOKOGAWA assumes no liability for the customer’s failure to comply with these requirements. The following Symbols Are Used on This Instrument.
  • Page 4 AQ7277B emits may damage the device. Be sure to install an appropriate blocking filter and check that the device’s ratings are adequate before making measurements.

  • Page 5: Authorized Representative In The Eea

    1: Under single fault conditions. Authorized Representative in the EEA Europe B. V. is Authorized Representative of Yokogawa Test & Measurement Corporation in the EEA for this Product. To contact Yokogawa Europe B. V., see the separate list of worldwide contacts, PIM 113-01Z2.

  • Page 6: Specifications

    This product is a Class A (for industrial environments) product. Operation of this product in a residential area may cause radio interference in which case the user will be required to correct the interference. Environmental Standard EN 50581 monitoring and control Instruments including those for industrial use 6/12 IM AQ7277B-01EN...

  • Page 7: External Dimensions

    ±0.3 mm when below 10 mm). 4-M3 Component Names USB port Power supply Rear (type B) ports Ventilation holes LED connector DC INPUT LED I/F OTDR(SMF) λ=xxxx nm 12 V 2.5 A Ventilation holes Ethernet port Optical connector M3 screws (four locations) IM AQ7277B-01EN 7/12...

  • Page 8: Installation

    Si vous obstruez les orifices de ventilation sur les panneaux avant et arrière de l'AQ7277B, l'AQ7277B se chauffera peut tomber en panne. Fix the AQ7277B in place using the six M3 screws (screw tightening torque: 0.6 to 0.7 N•m). Adjust each screw so that the portion of the screw that is inserted into the AQ7277B case is 3 mm to 6 mm in length. M3 screws...

  • Page 9: Connecting Optical Fiber Cables

    Connecting a Optical Cable to the AQ7277B Connect the optical cable to the optical connector of the AQ7277B. CAUTION Insert the optical fiber cable connector slowly and straight into the optical port. If you shake the connector to the left and right or force it into the port, the optical connector may be damaged.

  • Page 10: Connecting To The Power Supply

    • Ne pas déposer des objets sur le câble d'alimentation, et le tenir éloigné des sources de chaleur. • Utilisez un adaptateur secteur qui répond aux puissances AQ7277B. • Utilisez un adaptateur de courant alternatif avec une corde de pouvoir qui rencontre les normes appropriées de la région dans laquelle vous l'utilisez.

  • Page 11: Power-On Operation

    Control window of the OTDR Remote Controller that is displayed in the PC monitor window Top menu For instructions on how to install the Remote Controller and how to connect the AQ7277B to a PC, see the User’s Manual IMAQ7277B-61EN (Remote Controller for the AQ7277B Remote OTDR: Configuring Network Settings and Updating the Firmware).
  • Page 12 RJ45 Port number: 10001/tcp Note • To use the Ethernet interface, you need obtain the communication library. Download it from the YOKOGAWA Web page. • To use the Ethernet interface, you need to configure the TCP/IP settings in advance. Configure them using the dedicated software, Yokogawa OTDR Remote Controller. You can download the software from the YOKOGAWA Web page. https://tmi.yokogawa.com/library/ 12/12 IM AQ7277B-01EN...
