PTI security systems APEX Installation And Operation Manual page 43

Extended Door Ctls: DISABLED
Press * to Change
PRESS # WHEN DONE
Door Relay Time
In seconds: 000
PRESS # WHEN DONE
Max Door Open Time
In seconds: 00000
PRESS # WHEN DONE
Presence Input Req. NO
Press * to Change
PRESS # WHEN DONE
Intercom Call Report: NO
Press * to Change
PRESS # WHEN DONE
Change the Displayed Site
Name?
Press * for YES
Press # for NO
rev. 7-2017 114A3863.E
Sets the extended door controls and
requires the
ENABLED, the device allows control of a
door with request to exit inputs and hold
open alarm notification.
Input 1 is used for the door alarm contact
and Input 2 is used for the request to exit
device contact. Relay 1 is used to activate
the door strike so that it will open and Relay
2 is used to activate a hold open device for
the door. Factory default is DISABLED.
The length of time (in seconds) for the door
relay to be active. The user must open the
door during this period of time or the door
will not open. The maximum value is 255
seconds. Factory default is 2 seconds.
The number of seconds the door can be
held open before an alarm is sent to the
controller. If a door is open over this time,
the alarm will sound. The maximum value
is 65,535 seconds. The maximum value
translates to 1,092.25 minutes (65535
seconds / 60 seconds per minute) or 18.2
hours (65535 seconds / 3600 seconds per
hour). This feature is available when using
extended door controls. Factory default is
30 seconds.
Requires optional inputs.
be active before a code can be entered.
Used when a vehicle sensor is required in a
driveway or traffic area.
When set to YES, Input #3 is dedicated
to this function and cannot be used as an
alarm input. Factory default is NO.
Requires optional
controller to report an intercom call.
When set to YES, Input 4 is used for
intercom calls.
of the connection depends on the type of
intercom. This option requires an intercom
call button. Factory default is NO.
Allows change to the site name screen
If YES is selected, setup will
display.
proceed to the following step. Select NO to
jump to the last parameter
APEX Access Device
optional inputs.
Input #3 must
inputs. Allows the
The exact configuration
When
39
