PTI security systems APEX Installation And Operation Manual page 39

Sound Buzzer w/Alarm: NO
Press * to Change
PRESS # WHEN DONE
Current Language:
ENGLISH
Press * to Change
PRESS # WHEN DONE
Time Format:
12 Hr.
Press * to Change
PRESS # WHEN DONE
Relay #2 Function:
AUX. OUTPUT
Press * to Change
PRESS # WHEN DONE
When Relay #2 is set for:
SLAVE TO RELAY #1
When Relay #2 is set for:
DIFFERENT HOLD TIME
Relay #2 Hold Time
In seconds: 001
PRESS # WHEN DONE
rev. 7-2017 114A3863.E
Controls the internal buzzer used to provide
audible feedback when a system alarm
occurs. When set to YES, the internal buzzer
will sound whenever an alarm occurs and
will remain on until the alarm resets from
the controller. When set to NO, the internal
buzzer will not sound when an alarm occurs.
Factory default is NO.
Allows user messages to be displayed in
one of nine languages. The other languages
are French, Spanish, Danish, Norwegian,
German, Dutch, Portuguese, and Italian.
Only user messages are changed, the setup
functions remain in English. Factory default
is English.
Controls how the time is displayed. Options
are 12 Hour and 24 Hour. The 12 Hour
displays the time as HH:MM:SS followed
by am or pm. The hour will be displayed
as 12:00:00 am to 12:00:00 pm. The 24
Hour format displays the time as HH:MM:SS
without the am or pm indicator. The hour
will be displayed as 00:00:00 to 23:59:59.
The factory default of 12 Hour.
Controls the function of Relay 2. Options are
ALARM OUTPUT, HOLD OPEN BY TIME,
SLAVE TO RELAY 1, DIFFERENT HOLD
TIME, and AUX. OUTPUT. Each option is
described in detail. The factory default is
AUX. OUTPUT
Causes Relay 2 to operate at the same time
as Relay 1. This allows it to be used for a
secondary device without having to put in a
separate isolation relay.
Relay 2 operates at the same time as Relay 1
but is activated for a different length of time.
This is useful when dual gate operators or
door holders are used that require different
activation times. When this option is
selected, the following prompt will appear.
Sets the hold time for Relay 2 when Relay 2
has a DIFFERENT HOLD TIME from Relay
1. The maximum time is 255 seconds
APEX Access Device
35
