APEX Access Device
L
• This function causes Relay 2 to trigger at the same time as Relay 1 but
remain active for a different length of time.
• Using the previous example, the two gates may require different trigger
times. The barrier gate may require a hold time of 1 second and the slide
gate a hold time of 5 seconds. In this case, use the
option.
This function can also be used to activate a door holder. See Using Extended
Door Controls for more information.
This the default setting
•
external device or secondary access point.
• It responds just like a relay on the relay board. This function is useful for
lighting zones, elevators, or additional gates or door strikes.
• This feature is set up in the control software.
• This function allows the second relay to activate for a certain period of
time each day. If two gates are used, it is possible to keep the secondary
gate open during certain hours. .
• For this configuration, select the
hours for Relay 2 to Active. Every day of the week can have different open
and close hours.
• For example, a site may want the slide gate across the main entrance
to stay open during regular business hours and use the barrier gate for
access. After hours, both gates remain closed and must activate to allow
entry and exit.
26
Different Hold Time.
UX Output.
where Relay 2 can be used for any
Hold Open By Time.
HOLD OPEN BY TIME
DIFFERENT HOLD TIME
option, then set the
