9700 Mobile Computer (CE)
STORAGE INFORMATION
Provides storage status of the internal storage (which is divided into System files and
User data) and external storage on the mobile computer.
Label
System
USER_DATA
Storage Card
STYLUS

Double-tap tab: Configures and tests double-tap sensitivity.

Calibration tab: Recalibrates the touch screen when it is no longer responding
correctly to stylus movement.
SYSTEM

General tab: Displays OS and system hardware information.

Device Name tab: Tap a name and description for the mobile computer.

Copyrights tab: Views copyright statements.
SYSTEM INFORMATION
Displays some of the mobile computer's info such as manufacturer, firmware version,
MAC address, memory capacity and so on. Tap each node to expand the tree structure
list and view data about the given items.
This page also displays the mobile computer's Device ID, a sequence of digits that
deliver information about the hardware integrated on the mobile computer. The coding
rule is tabulated as below:
132
Description
Shows total size and available size of storage under the System directory.
Shows total size and available size of storage under the USER_DATA
directory.
Shows total size and available size of storage on the storage card.
Digit
Pair Hardware
st
1 Barcode
Reader
--
nd
2
rd
3 Bluetooth
th
4 Wi-Fi
--
th
5
Reference Manual
Code
0: None:
1: Laser
2: Laser
3: 2D imager
4: Long range laser
5: 2D imager
7: Extra long range 2D
imager
9: Extra long range laser
N/A
0: None
1: Bluetooth
0: None
1: Wi-Fi
N/A
