Carrier 30XV140-500 Installation Instructions Manual

CONTENTS
SAFETY CONSIDERATIONS. . . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Configuration (All Sizes) . . . . . . . . . . . . . . . . . . . . . . . . . 5
Temperature Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
• 4 TO 20 mA
• SPACE TEMPERATURE
Demand Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
• 4 TO 20 mA
• SWITCH CONTROLLED
Additional EMM Functions . . . . . . . . . . . . . . . . . . . . . . . 6
• INPUTS
• OUTPUTS

SAFETY CONSIDERATIONS

Installation of this accessory can be hazardous due to sys-
tem pressures, electrical components, and equipment location
(such as a roof or elevated structure).
Only trained, qualified installers and service technicians
should install, start up, and service this equipment.
When installing this accessory, observe precautions in the
literature, labels attached to the equipment, and any other
safety precautions that apply.
• Follow all safety codes.
• Wear safety glasses and work gloves.
• Use care in handling and installing this accessory.
WARNING
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation. There
may be more than one disconnect switch. Tag all discon-
nect locations to alert others not to restore power until work
is completed.

GENERAL

The standard Touch Pilot
all 30XV chillers is programmed to accept various options to
modify the unit operation. The Energy Management Module
(EMM) board is required for 4 to 20 mA, 2 or 3-step demand
limit control, chilled water temperature reset by space tempera-
ture or 4 to 20 mA, and Ice Mode. Chilled water temperature
reset by return water or cooler delta T does not require the addi-
tion of this accessory. See Table 1 for EMM functions. The fol-
lowing functions are available with the EMM board:
• Chilled Water Temperature Reset - Resets the chilled
water set point under less than full load capacity condi-
tions by the following methods:
4 to 20 mA Input: A field-supplied signal generator
-
and 1 / -watt, 250-ohm resistor are required.
2
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53300200-01
Energy Management Module Accessory
Installation Instructions
Part No.: 30XV70000701
™ controls software provided on
Printed in U.S.A.
Space Temperature: A field-supplied space tempera-
-
ture sensor is required.
Page
• Demand Limit - Limits the capacity of the machine from
unit capacity by the following methods:
4 to 20 mA Input: A field-supplied signal generator
-
and 1 / -watt, 250-ohm resistor are required.
2
2 or 3-Step Switch Control: A field-supplied dry con-
-
tact switch is required (One-Step Demand Limit does
not require the EMM board).
• Occupancy Override - Extends the occupied period for
machine operation. A field-supplied dry contact switch is
required.
• Remote Chiller Lockout - Disables the chiller when
closed. A field-supplied dry contact switch is required.
• Ice Done Control Switch - Signals the machine to exit
the Ice Build mode and enter an unoccupied time period.
A field-supplied dry contact switch is required.
The following status functions are available with the EMM
board:
• Capacity Output Signal - A 0 to10 vdc analog output
signal indicating chiller capacity is available.
• Shutdown Status Relay - A 24 vac output signal indi-
cating that the machine is shutting down.
• Alert Relay - A 24 vac output signal indicating the unit
has an active alert.
• Compressor Run Status - A 24 vac output signal (one
for compressor A, one for compressor B), indicating the
compressor is on.
The EMM board can be configured with the Touch Pilot
module.
Table 1 - EMM Functions by Unit
INPUTS
OUTPUTS

Package Contents -

for correct part numbers. Refer to Table 2 for package con-
tents and usage. If any of the components are damaged, file
a claim with the shipping company and notify your Carrier
representative.
Form 30XV-9SI
30XV140-500
INPUT/OUTPUT
Demand Limit, 2 or 3-Step
Demand Limit, 4-20 mA
Ice Done
Occupancy Override
Space Temperature Thermistor
Remote Chiller Lockout
Temperature Reset, 4-20 mA Signal
Temperature Set Point, 4-20 mA Signal
Alert Relay
Compressor A Run Status
Compressor B Run Status
Shutdown Status Relay
Total Capacity Output, 0-10 vdc
Examine the package contents
Pg 1 9-17 Replaces: New
