installation & setup
step two
Check for the following wires:
1
HOT or LINE: Receives power from the circuit box. Referred to as "hot" for the
purposes of this guide. Do not touch or let "hot" wires contact other wires.
2
LOAD: Directs power to your light(s).
3
NEUTRAL: Creates a path to return current to the power source when the
device is off. Required for your switch installation.
4
GROUND: Provides a safe path for electricity in the event of a short circuit.
TRAVELER: If more than one switch controls the light, an additional wire will be in
5
the box that "travels" to the other switch.
NOTE: Refer to the "faqs" on page 23 if you are unsure of your wiring.
8
|
remove the existing device
