LEGRAND The Radiant Collection Installation Manual page 10

installation & setup
step three
Use the wire nuts provided to secure the wires together.
1 Connect the WHITE neutral wire on the switch to the neutral wires in the box, using
the red wire nut.
2 Connect the LOAD wire on the switch to the load wire in the box.
3 Connect the HOT wire on the switch to the hot wire(s) in the box.
4 Connect the GREEN ground wire on the switch to the ground wire(s) in the box.
5 If the light is controlled with only one switch, use a wire nut to cap the YELLOW
traveler wire on the device. If more than one switch controls the light, connect the
YELLOW traveler wire on the device to the wire going to the other switch.
NOTE: This product will work with existing three-way switches. The switch can be installed
in either location.
10
|
wire the smart switch
