Kramer TS-1WUS Installation Instructions

Dual insert us power socket module for inner frame, modular pop-up, and utbus

Installation Instructions

MODEL:

TS-1WUS

for Inner Frame, Modular Pop-up, and UTBUS

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information on our products and a list of Kramer distributors, visit our Web site where

updates to these installation instructions may be found.

We welcome your questions, comments, and feedback.

www.KramerAV.com

info@kramerel.com

Dual Insert US Power Socket Module

P/N:

2 9 0 0 - 3 0 0 8 8 8

Rev:

Table of Contents

Do you have a question about the TS-1WUS and is the answer not in the manual?

Page 1: Installation Instructions
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to these installation instructions may be found. We welcome your questions, comments, and feedback.
Page 2 Dual Insert US Power Socket Module Congratulations on purchasing your Kramer TS-1WUS dual insert US power socket module for Inner Frame, Modular Pop-up, and UTBUS. Figure 1: TS-1WUS Feature Function Front plate Attach to TBUS frame with four screws. Power output socket Connect to device for power supply.
