- Page 1 USER MANUAL MODEL: KRT-3 Cable Retractor P/N: 2900-301069 Rev 2 www.KramerAV.com...
-
Page 2: Table Of Contents
Introduction Getting Started Overview Typical Applications Defining the KRT-3 Cable Retractor Installing KRT-3 Attaching KRT-3 to the Underside of a Table Attaching KRT-3 to a TBUS Connecting to the KRT-3 Technical Specifications KRT-3 Outline Dimensions with TBUS KRT-3 – Contents... -
Page 3: Introduction
European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling. -
Page 4: Overview
You can also install one or more KRT-3 units in conjunction with a Kramer TBUS unit, such as TBUS-1AXL, TBUS-10XL, TBUS-203XL (with installation kit for pop-up TBUS) and more. -
Page 5: Defining The Krt-3 Cable Retractor
Kramer Electronics Ltd. Defining the KRT-3 Cable Retractor This section defines the KRT-3. Figure 1: Defining the KRT-3 Cable Retractor Feature Function Retractor Enclosure Contains the retractable cable mechanism. Female Connector Connect to a male connector under a table. Fixed Cable End Short connector cable. -
Page 6: Installing Krt-3
Table, on page 4. • Attaching KRT-3 to a TBUS, on page 5. Attaching KRT-3 to the Underside of a Table You can mount KRT-3 to the underside surface of a table and use it as a standalone device. To attach KRT-3 under a table: 1. -
Page 7: Attaching Krt-3 To A Tbus
Kramer Electronics Ltd. Attaching KRT-3 to a TBUS You can attach one or more KRT-3 units to the enclosure of any modular Kramer TBUS with pass-through inserts that are installed inside a table. The KRT-3 units can usually be attached to the front and rear sides of the enclosure, as the left and right sides are fitted with clamps. - Page 8 2. Use the locking Allen screw to fix the KRT-3 firmly in place. Figure 4: Tightening KRT-3 to the TBUS Enclosure KRT-3 is now firmly fixed in place. Figure 5: KRT-3 Attached to TBUS – Under Table KRT-3 – Installing KRT-3...
- Page 9 You can attach several KRT-3 units to a Kramer TBUS: • For TBUS units with a sliding cover (for example, the Kramer TBUS-10xl), attach the KRT-3 units side-by-side to the front side of the TBUS enclosure (Figure Figure 6: Attaching Several KRT-3 Units to TBUS with Sliding Cover...
- Page 10 Kramer Electronics Ltd. • For TBUS units with a regular cover (for example, the Kramer TBUS-1Axl), attach the KRT-3 units side-by-side to the front and rear side of the TBUS enclosure (Figure To maximize the number of KRT-3 units that can be attached to...
-
Page 11: Connecting To The Krt-3
Kramer Electronics Ltd. Connecting to the KRT-3 You can connect the following devices to the KRT-3. Figure 8: Connecting KRT-3 KRT-3 – Connecting to the KRT-3... -
Page 12: Technical Specifications
26.5cm x 34.5cm x 7.2cm (W, D, H) (10.4" x 13.6" x 2.8") Net Weight 0.75kg (1.7lbs) approx. Shipping Weight 1.3kg (2.9lbs) approx. Accessories Included 4 M3x8 screws Specifications are subject to change without notice at www.kramerav.com KRT-3 – Technical Specifications... -
Page 13: Krt-3 Outline Dimensions With Tbus
Kramer Electronics Ltd. KRT-3 Outline Dimensions with TBUS The following diagram shows the outline dimensions [cm] of a KRT-3 unit attached to a TBUS (for example, the Kramer TBUS-1Axl). Figure 9: KRT-3 Attached to TBUS – Dimensions KRT-3 – Technical Specifications... - Page 14 Electronics products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re- installation of this product from or into any installation.
- Page 15 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback.
