3
IDAS OPERATION

■ Transmitting Position data

When a GPS receiver is connected to the transceiver, the
position (longitude and latitude) data can be automatically
transmitted:
• When the GPS request status message is received
• After sending a voice message
- Set the 'Send with Voice Call' item to 'Enable.'
• After sending a status message
- Set the 'Send with Status Call' item to 'Enable.'
• After sending a message
- Set the 'Send with SDM Call' item to 'Enable.'
• After sending a Call Alert
- Set the 'Send with Call Alert' item to 'Enable.'
• After sending an Emergency call
- Set the 'Send with Emergency' item to 'Enable.'
Ask your dealer or system operator for connection details.
15
■ Transmitting Status messages
A status message can be automatically transmitted.
A status message is transmitted:
• When the transceiver is turned ON or turned OFF
- Set a status message to be transmitted in 'Power ON Status' or
'Power OFF Status' item, respectively.
- Set the target station ID in 'Power Status ID.'
• After sending a voice message
- Set the 'Send with Voice Call' item to 'Enable.'
- Set a status message to be transmitted in the 'Send Status
Number' item.

■ Sounding a Horn

The automatic honking function can be used when a horn is
connected to the transceiver through the optional ACC cable
OPC-1939 (D-Sub 15-pin) or OPC-2078 (D-Sub 25-pin).
When a status message is received, the transceiver sounds
the vehicle's horn for the specified time period to inform you
that a status message has being received.
This function is convenient when the operator is away from
the transceiver.
Ask your dealer or system operator, or refer to the IC-F5120D/
F6120D series service manual for connection and setting details.
