  • Page 1 MARS-3070 Tablet PC...
  • Page 2 All other product names or trademarks are properties of their respective owners. Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase.
  • Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 4 IEEE recommended practice for the measurement and computations of radio frequency electromagnetic fields with respect to human exposure to such fields, 100kHz-300GHz. EN 300 328 V1.7.1 (2006-10) Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques;...
  • Page 5 Cesky [Czech] [Advantech] tímto prohlaáuje, _e tento [MARS-3070] je ve shodì se základními po_adavky a daláími pøísluánðmi ustanoveními smìrnice 1999/5/ES. Dansk [Danish] Undertegnede [Advantech] erklærer herved, at følgende udstyr [MARS-3070] overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 6 Visit the Advantech web site at where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: œ...
  • Page 7 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Wichtige Sicherheishinweise Bitte lesen sie Sich diese Hinweise sorgfältig durch.
  • Page 8 Entsorgen Sie Batterien nach Anweisung des Herstellers. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab.

  • Page 9: Table Of Contents

    Contents Safety Information ........................iii Contents ............................v Chapter 1: Using This Manual ....................1 Conventions..........................1 Bold Text ..........................1 Symbols ..........................1 Terminology ........................... 2 Notes and Important Messages ..................... 2 Procedures..........................2 Chapter 2: Introduction......................3 Functional Description ........................3 Technical Specifications .......................
  • Page 10 Contents Disposing of the Battery Pack ....................23 Index ............................25...

  • Page 11: Chapter 1 Using This Manual

    Using This Manual Chapter 1 This manual contains tool usage instructions. Some of the illustrations shown in this manual may contain modules and optional equipment that are not included on your system. Contact your sales representative for availability of other modules and optional equipment.

  • Page 12: Terminology

    Using This Manual Conventions 1.1.3 Terminology The term “select” means highlighting a button or menu item using the Thumb Pad and pressing the Y/a button to confirm the selection. Example: Select Reset. • The above statement abbreviates the following procedure: 1.

  • Page 13: Chapter 2 Introduction

    Introduction Chapter 2 The VERDICT™ Diagnostic Platform is a specialized personal automotive diagnostic solution that combines information with test instrumentation to help you diagnose symptoms, codes, and complaints quickly and efficiently, test vehicle systems and components, access service records and recorded data, and verify repairs. There are three main components to the VERDICT system: Display Device—the processor and monitor •...
  • Page 14 Introduction Functional Description Left Side Right Side Figure 2-2 Model D7 side views 1— USB (universal serial bus) Ports (2) 2— Microphone Port 3— Audio (head phone) Port 4— DC Power Supply Input Port 5— SD (secure digital) Card Port 6—...

  • Page 15: Technical Specifications

    Introduction Technical Specifications 2.2 Technical Specifications Processor: Intel Atom Z510 Operating System Microsoft Windows XP Embedded SP2 Touch Screen 4-wire Resistive Touch Panel Display: 7 inch diagonal, LCD TFT 1024 x 600 resolution 16 bit color Battery: Lithium Ion Smart Battery Pack Approximately 3.5 hour run time Approximately 4 hour charge time, unit not operating Approximately 8 hour charge time, unit operating...

  • Page 16: Navigation, Controls, And Features

    Introduction Navigation, Controls, and Features Storage Temperature (ambient): At 0 to 70% relative humidity (non-condensing) –4 to 140°F –20 to 60°C Environmental Conditions: This product is intended for indoor use only This product is rated for Pollution Degree 2 (normal conditions) Power Supply: Supply Rating;...

  • Page 17: Leds

    Introduction Power Sources 2.3.2 LEDs There are two light-emitting diodes (LEDs) on the front face of the device: Power Indicator LED—this device uses three colors to show the batteryand power status as • follows: – Green indicates a either a battery with a full, or nearly full, charge or DC power Orange indicates a battery that is charging.

  • Page 18: Charging Station (Optional)

    Introduction Power Sources The unit can be powered and operated when installed on the optional charging, or docking station. The docking station also powers the internal battery pack charging process and allows USB connectivity for attaching peripherals. Contact your sale representative for additional details.

  • Page 19: Chapter 3 Getting Started

    Getting Started Chapter 3 Make sure the VERDICT D7 has a charged battery or is connected to an AC power supply (see “Power Sources” on page 7). It is highly recommended to back up personal and saved data to a USB mass storage device on a regular basis to prevent loss in the event of system corruption or hard disk drive failure.

  • Page 20: Module Buttons

    Getting Started Powering Up 3.1.1 Module Buttons The Module buttons configure the VERDICT for the type of test to be performed. The table below gives brief descriptions of the available Module buttons, which operations are available depends upon the individual configuration of your VERDICT system. Table 3-1 Module buttons (sheet 1 of 2) Name...

  • Page 21: Verdict Toolbar

    Getting Started Powering Up Table 3-1 Module buttons (sheet 2 of 2) Name Button Description Configures the unit to operate as a Scanner scan tool. Opens a window that contains details System Properties about the configuration of your VERDICT system. Closes the VERDICT diagnostic Exit Platform software and returns to the...

  • Page 22: Powering Down

    Getting Started Powering Down 3.2 Powering Down All vehicle communication must be terminated before shutting down the VERDICT unit. Failure to do so may lead to ECM problems on some vehicles. Exit the Scanner module before powering down the VERDICT unit. To power down the VERDICT unit: 1.

  • Page 23: Chapter 4 Operations

    Operations Chapter 4 This section explains tests and operations that pertan to the display device only, or apply to all of the available modules. Included here are discussions of: • Vehicle ID Help • Data Manager • 4.1 Vehicle ID The Vehicle ID refers to any work in progress, such as a repair order, estimate or invoice, that has customer, vehicle, and repair information for a vehicle in your shop.

  • Page 24: Vehicle Id Toolbar

    Operations Vehicle ID 4.1.1 Vehicle ID Toolbar The table below gives brief descriptions of the control buttons on the toolbar: Table 4-1 Toolbar buttons Name Button Description Add New Use to create a new Vehicle ID Use to quickly access generic OBD-II OBD Direct data without a Vehicle ID Use to modify and add notes to a...
  • Page 25 Operations Vehicle ID 2. Enter the year, make, and model of the test vehicle using either the dropdown menus or the virtual keyboard. NOTE: Year, make, and model are required fields, all other information on the dialog box is optional. 3.
  • Page 26 Operations Vehicle ID Figure 4-3 Sample Display Options dialog box. 1— Select All Button 2— Deselect All Button Individual selections must be made one at a time. To change a display option: 1. Highlight the item to change with the stylus. items with a checked box display on the screen –...

  • Page 27: Vehicle Id Main Body

    Operations Help To search: 1. Use the virtual keyboard to enter search criteria. 2. Use the dropdown menu to select the field to search. 3. Select Find Now to start the search. 4. Select OK to close the Search window. After a search, the Select All button becomes available on the toolbar.
  • Page 28 Operations Help A tool bar just below the options buttons is used to navigate the HTML file. Toolbar operations are explained in the table below: Table 4-2 Help toolbar buttons Name Button Description Back Returns to the previously viewed page Next Advances to the next page Stop...

  • Page 29: Data Manager

    Operations Data Manager 4.3 Data Manager Select Data Manager on the Module toolbar to open the file system. Use the toolbar at the top of the screen to navigate through the data. The folders panel below the toolbar displays the contents of the Windows “My Documents”...
  • Page 30 Operations Data Manager Table 4-3 Help toolbar buttons (sheet 2 of 2) Name Button Description Copy Copies the selected file or folder. Move Relocates the selected file or folder. Displays information about the selected Properties file or folder. Save Saves the selected file. Creates a shortcut for the selected file Shortcut or folder.

  • Page 31: Chapter 5 Maintenance

    Maintenance Chapter 5 This section covers how to care for your VERDICT Display Device. 5.1 Cleaning the Touch Screen The touch screen can be cleaned with a soft cloth and alcohol or a mild window cleaner. IMPORTANT: Do not use any abrasive cleansers or automotive chemicals on the touch screen. 5.2 Cleaning and Inspecting the Unit When using the VERDICT unit, make sure to do the following: Check the housing, wiring, and connectors for dirt and damage before and after each use.

  • Page 32: Battery Safety Guidelines

    Maintenance Battery Service WARNING Risk of explosion. • The Lithium battery is factory replaceable only, incorrect replacement or tampering with the battery pack may cause an explosion. Explosion can cause death or serious injury. 5.3.1 Battery Safety Guidelines IMPORTANT: The battery pack contains no user serviceable components. Tampering with the battery pack terminals or housing will void the product warranty.
  • Page 33 Maintenance Battery Service To replace the battery pack: 1. Remove the two captive screws the secure the battery pack to the back of the unit. 2. Insert a fingernail into the recess at the mid point of the top of the battery pack, then gently raise the battery pack up to release the electrical connector.
  • Page 34 Maintenance Battery Service Figure 5-2 sample WEEE logo NOTE: Always dispose of materials according to local regulations. Contact your sales representative for details.
  • Page 35 Index safety information iii AC/DC power supply 7 message conventions iii safety messages iii – stand, the 7 battery pack 7 storage temperature 6 disposing of 23 handling 22 replacing 22 temperature specifications 5 operating 5 storage 6 charging station 8 cleaning the unit 21 vehicle identification 13 –...
