User Manual

AIM-68H Series

10.1" Windows Tablet PC

Need help?

Do you have a question about the AIM-68H-202000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Advantech AIM-68H-202000

Page 1 User Manual AIM-68H Series 10.1” Windows Tablet PC...
Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
Page 3 Declaration of Conformity CE Conformity Statement Radio products with the CE alert marking comply with the RED Directive (2014/53/ EU) issued by the Commission of the European Community. Compliance with this directive implies conformity to the following European Norms (in brackets are the equivalent international standards).
Page 4 ence to radio or television reception, which can be determined by turning the equip- ment off and on, the user is encouraged to try to correct the interference by one of the following measures: ◼ Reorient or relocate the receiving antenna. ◼...
Page 5 could cause interference and/or damage to LE-LAN devices. Le present emetteur radio a ete approuve par Industrie Canada pour fonctionner avec les types d'antenne enumeres ci-dessous et ayant un gain admissible maximal et l'impedance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est superieur au gain maximal indique, sont stricte- ment interdits pour l'exploitation de l'emetteur: (i) l'appareil pour fonctionner dans la bande 5150-5250 MHz est réservé...
Page 6 Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –...
Page 7 Discard used batteries according to the manufacturer's instructions.” Note! Notes provide additional optional information. Document Feedback To assist us with improving this manual, we welcome all comments and constructive criticism. Please send all such feedback in writing to support@advantech.com. AIM-68H User Manual...
Page 8 Packing List Before system installation, check that the items listed below are included and in good condition. If any item does not accord with the list, contact your dealer immediately. ◼ Quantity x Item XXXXXXXX ◼ 1 x User manual Safety Precautions - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage.
Page 9 VCCI Marking China RoHS 10 year life time Symbol BSMI Marking Directive 2012/19/EU : The WEEE Symbol E-Mark TELEC Marking NCC Marking Serial Number Marking Production Identifier: Lot Number Marking GTIN code Symbol Manufacture Date (YYMMDD) Marking European Authorized Representative Marking Swiss Authorized Representative Marking Medical Device Marking Packaging Marking (Temperature, Atmospheric Pressure and Humidity)
Page 10 Retain this user manual for future reference. Repair of the device may also only be carried out by trained service personnel. Advantech recommends that a service contract be obtained with Advantech Service and that all repairs also be carried out by them. Otherwise the correct functioning of the device may be compromised.
Page 11 Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle marked “Hospital Only” or “Hospital Grade”. Use a power cord that matches the voltage of the power outlet, which has been approved and complies with the safety standard of your particular country. If the integrity of the protective earth conductor is in doubt.
Page 12 Jetez les piles usagées conformément aux instructions du fabricant. Caution! When servicing the device, always use replacement parts that meet Advantech standards. Advantech Medical cannot warrant or endorse the safe performance of third-party replacement parts for use with our medical device.
Page 13 Notice: To prevent unauthorized access, it is recommended to install suitable anti-virus software or do not connect to unsafe external networks DISCLAIMER: These instructions are provided according to IEC 704-1 stan- dards. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
Page 14 Contents Chapter Getting Started ........Unpacking ....................... 2 1.1.1 Inside the Box: Standard..............2 1.1.2 Optional Accessories ................ 2 1.1.3 Optional Docking & Station ............... 2 AIM-68H at a Glance & Description of Parts ..........3 Chapter Using the Tablet ........Battery Caution ....................
Page 15 Chapter Getting Started...
Page 16 1.1 Unpacking 1.1.1 Inside the Box: Standard Tablet PC Power Adaptor Your package may include below peripherals based on your order. 1.1.2 Optional Accessories ◼ Shoulder Strap Shoulder Strap 1.1.3 Optional Docking & Station ◼ Office Docking ◼ VESA Docking VESA Docking Desk Docking AIM-68H User Manual...
Page 17 1.2 AIM-68H at a Glance & Description of Parts Item Description of Parts 5.0-megapixel fixed-focus camera. 5MP Front Camera NFC Reader NFC card reader Ambient Light Sensor The goal of this application is to improve the visual experience and make the lighting comfortable for user. Digital Mic Capture audio input.
Page 18 Chapter Using the Tablet...
Page 19 2.1 Battery Caution Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the same type recommended by the manufacturer, discard used batter- ies according to the manufacturer's instructions. Danger d'explosion si la batterie est inexactement remplacée. Rem- placez seulement avec la même chose ou le type recommandé...
Page 20 2.2 Connecting to Power Supply The Tablet Computer operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet Computer for the first time. Warning! Use only the AC adapter that included with your Tablet PC. Using other AC adapters may damage the Tablet PC and the Battery.
Page 21 2.2.3 Plug the AC adapter into the USB Type-c port of the Tablet pc. When the AC Adapter is connected, the battery pack starts charging. The battery LED indicator on the tablet pc would show different states. Please refer to description of LED indicator on Description of Parts.
Page 22 2.3.2 Turning off To turn off the device, press the start button, then click power, tap the Shut down AIM-68H User Manual...
Page 23 Touch Screen Operation 2.4.1 The Touchscreen Supports Core Gesture for Windows Caution! The touchscreen is designed to be touched gently with your fingers. Do not press it strongly with your fingers or push into it with a pointed object such as your nail, pen, or a pin, etc. Gesture Action Description...
Page 24 Rapidly touch surface twice with fin- Double-Tap gertip. 2.4.2 Cleaning and Disinfecting Instruction During normal use of the AIM tablet the device may become dirty and should be reg- ularly cleaned. 2.4.2.1 Turn off the AIM-68H and unplug the power cord. 2.4.2.2 Wipe the screen and exterior with a soft, damp cloth moistened only with water.
Page 25 Using the Strat Button Start your Windows 10 from the Start Button Browse every app User User account setting or sign out for other users Find files Find pictures Settings Personalize the defaults, Monitors, networks, and more. Shut down Button Sleep, Shut down, Restart The Start Button...
Page 26 Using the Windows Taskbar Search bar Network The Start Button Task View Date/Time Find anything on your Wi-Fi, In the lower-left Get back to device by entering airplane Calendar corner, it puts what something your search here. mode and clock you need at your you were fingertips.
Page 27 2.9 Using the Windows Setting Search Box Faster results using search box. Settings Personalize your tablet with Windows Settings. AIM-68H User Manual...
Page 28 Chapter Networks and Wireless Devices...
Page 29 3.1 Connecting to Wi-Fi Network Click , the device scans for available Wi-Fi networks and displays the list of it. Secured networks are indicated with a lock icon. If the network is open, just click on it to connect. If the network is secure, users need to enter a password or other credentials AIM-68H User Manual...
Page 30 3.2 Adding Wi-Fi Network Turn on Wi-Fi and Tap Network & Internet settings. AIM-68H User Manual...
Page 31 Click Wi-Fi, then tap Manage known networks. AIM-68H User Manual...
Page 32 Click Add a new network, then setup Network name/Security type/Security key and save the network. AIM-68H User Manual...
Page 33 3.3 Connecting Bluetooth Device to Tablet Go into Windows Settings, tap Devices. AIM-68H User Manual...
Page 34 Tap Add Bluetooth & other devices. AIM-68H User Manual...
Page 35 Tap Bluetooth. Tap the device you want to connect, then connected device will show in your devices. AIM-68H User Manual...
Page 36 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022 AIM-68H User Manual...
