Tablet PC AIM-89H Series
Startup Manual

Table of contents

1. Appearance & Description......1
2. Easy Setup..........................2
3. Safety Instruction..................3
4. Battery caution.....................5
6. Exploring the device................6
For more information on this and other
Advantech products, please visit our website
at:
https://www.advantech.com/
For technical support and service, please visit
our support website at:
https://www.advantech.com/contact
This manual is for AIM-89H
Series
Print in Taiwan
AIM-89H Appearance
Left: Front View
5th Edition
AUG 2024
Right: Rear View
Description of Parts
A
B C D
M
N
E
F
G
H
I J
K
O
A: Microphone
B: Camera LED
C: 5MP Front Camera
D: Light Sensor
E: Stereo Speaker (L)
F: Programable buttons
G: System LED
H: Volume buttons
I: Power Button
J: Power LED
LED Status
Color
Solid Green
Solid Blue
Blinking
Blue
K: Stereo Speaker (R)
L: Internet LAN Port,
HDMI output & USB 3.2 Type-C Port
Door
M: USB 3.0 Type-A *2
& 3.5mm Audio Combo Jack Door
N: DC-in Door
O: Pogo Pin (USB3.0 )
P: 8MP Rear Camera
Q: Flash LED
PQ
L
Status
Full charged (DC-in or
USB-C) Ready for use
Charging (DC-in or USB-
C)
Battery lower than 10%
1
