  • Page 1 User Manual MARS-3100R/S Industrial Tablet PC...

  • Page 2: Product Warranty (2 Years)

    A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. Part No. 2006310002 Printed in Taiwan MARS-3100R/S User Manual Edition 3 April 2008...

  • Page 3: Declaration Of Conformity

    Association, work sites are classified into different classes, divisions and groups, based on hazard considerations. This equipment is compliant with the speci- fications of Class I, Division 2, Groups A, B, C and D indoor hazards. MARS-3100R/S User Manual...

  • Page 4: Europe - Eu Declaration Of Conformity

    EN 301 489-17 V1.2.1 (2002-08) and EN 301 489-1 V1.4.1 (2002-08) Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment MARS-3100R/S User Manual...
  • Page 5 5470 – 5725 MHz. End-users are encouraged to contact the national spectrum authorities in France and Luxembourg in order to obtain the latest information about any restrictions in the 5 GHz frequency band(s). 0560 MARS-3100R/S User Manual...
  • Page 6 [Advantech] vakuuttaa täten että [tip opreme] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Svenska [Swedish] Härmed intygar [Advantech] att denna [tip opreme] står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. MARS-3100R/S User Manual...

  • Page 7: Technical Support And Assistance

    Note! Notes provide optional additional information. Document Feedback To assist us in making improvements to this manual, we would welcome comments and constructive criticism. Please send all such - in writing to: www.advantech.com/support support@advantech.com MARS-3100R/S User Manual where you can...

  • Page 8: Safety Instructions

    Safety Instructions Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. For plug-in equipment, the power outlet socket must be located near the equip- ment and must be easily accessible.

  • Page 9: Wichtige Sicherheishinweise

    Wichtige Sicherheishinweise Bitte lesen sie Sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.

  • Page 10: Product Labelling

    Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. To avoid electrical shock, always disconnect the power from your PC chassis before you work on it. Don't touch any components on the CPU card or other cards while the PC is on.

  • Page 11: Table Of Contents

    Figure 2.13 Auto touchscreen calibration ... 14 Figure 2.14 Accessing the Configuration Utility ... 15 Figure 2.15 Calibrating the touchscreen... 15 Figure 2.16 4 points calibration... 15 Figure 2.17 Draw test ... 16 Figure 2.18 Using the pen ... 17 USB ports... 18 MARS-3100R/S User Manual...
  • Page 12 3.4.1 3.4.2 Image Version... 38 Audio... 39 3.6.1 MARS-3100R/S User Manual Figure 2.19 USB port... 18 COM ports ... 18 Figure 2.20 COM port... 18 Audio jacks ... 19 Figure 2.21 Audio Jacks (Red: input and Green: output) ... 19 VGA port ...
  • Page 13 Incorrect removal of the HDD ... 62 Figure 4.7 Unplugging the cable connector ... 62 Figure 4.8 Removing the CF card... 63 Computer will not start ... 64 Computer does not resume operation after suspension ... 64 xiii ..57 MARS-3100R/S User Manual...
  • Page 14 Setting Up an Internet Connection... 74 Connect to the Internet by GPRS ... 78 INDEX MARS-3100R/S User Manual Computer will not enter into suspension mode... 64 Computer will not shut down... 64 Display remains off, or is not bright ... 64 Computer touchscreen does not respond to the pen...

  • Page 15: Chapter 1 Introduction

    Chapter Introduction This chapter gives basic data about the specifications and use of the MARS-3100R/S Tablet PC. Sections include: ! Welcome ! About this Manual ! System Specifications ! Environmental Standards...

  • Page 16: Welcome

    Welcome Congratulations on selecting the MARS-3100R/S Rugged Tablet PC, supported by Microsoft Windows® XP Embedded. This unique tablet PC offers a special combina- tion of features that make it an ideal partner for a wide range of applications. The main features of the MARS-3100R/S are: ®...

  • Page 17: Table 1.1: System Specifications

    System Specifications The MARS-3100R/S meets the following specifications. Unless otherwise noted, all the specifications listed below are subject to change without prior notification. Table 1.1: System Specifications Features Dimension W × D × H Weight Panel Touchscreen DRAM L2 cache...

  • Page 18: Environmental Standards

    - DOC Class B - Contact: 4Kv/ Air: 8Kv, EN55024 - UL / cUL, UL60950-1 Safety - CB, IEC/EN60950-1 MARS-3100R/S User Manual -10° C to 55° C* * Battery mode: 0°C @ 50% Battery capacity. * Adapter mode: Any ( MIL-STD 810F Methods 501.4 and 502.4 ) -40°...

  • Page 19: Chapter 2 Getting Started

    Chapter Getting Started This chapter details basic functions of the tablet PC and how to use it for the first time. Sections include: ! Check the Package ! General Views of the Tablet PC ! LED Indicator Signal Table ! Powering the tablet PC ! Starting the tablet PC ! Manual Touchscreen Calibration...

  • Page 20: Figure 2.1 Mars 3100R/S And Accessories

    Check the Package Each new MARS-3100R/S comes equipped with a range of product accessories and materials. Figure 2.1 Mars 3100R/S and Accessories A summary of the package contents: MARS-3100R/S Battery pack Adapter Pen (for MARS-3100S) or Digitizer Pen (for MARS-3100R)

  • Page 21: Figure 2.2 Front View

    General Views of the Tablet PC 2.2.1 Tablet front view 2.2.2 Tablet back view HDD Cover Battery Pack Front bezel buttons Figure 2.2 Front view Pen & Holder Heatsink Cover Figure 2.3 Back view MARS-3100R/S User Manual...

  • Page 22: Figure 2.4 Front Edge View

    Tablet right edge view USB Port (for MARS-3100R only) 2.2.6 Tablet left edge view Audio In RJ45 Port MARS-3100R/S User Manual Docking Port Figure 2.4 Front edge view WLAN On/Off Switch Figure 2.5 Rear edge view COM Port (COM3) SIM Slot (for GSM/GPR/EDGE models only) Figure 2.6 Right edge view...

  • Page 23: Figure 2.8 Status Leds

    LED Signals The MARS-3100R/S is equipped with a set of Light Emitting Diodes (LEDs) located along the top edge of the front bezel. Power On/Off LED HDD Status LED 2.3.1 Power ON/OFF LED Dark: System is turned OFF Static Green: System is turned ON.

  • Page 24: Hdd Status Led

    Prevent any shocks or vibrations whenever the HDD status LED is blink- ing. Violent shocks may cause damage to the HDD, and data loss. 2.3.4 Wireless LAN ON/OFF LED: Dark: Wireless LAN is disabled Static Green: Wireless LAN is enabled MARS-3100R/S User Manual...

  • Page 25: Figure 2.9 Buttons On The Front Bezel

    2.4.4 Hotkey buttons The F1 to F3 buttons are programmable hotkeys. Note! See Chapter 3.2.2, 3.3 for more information about setting up hotkeys and using buttons. Key button Display rotation button 5-way navigation button Hotkey buttons MARS-3100R/S User Manual...

  • Page 26: Figure 2.10 Inserting The Battery Pack

    2.5.1.1 Installing a Battery The battery is designed specifically for installation with the MARS-3100R/S tablet PC. It fits exactly into the back of the PC and delivers precisely the exact voltage required to power the unit. Under normal conditions, a fully charged battery will power the PC for up to 3 hours.

  • Page 27: Figure 2.12 Inserting The Dc Jack

    It can maintain system power for only 3 minutes. Before using the hot-swapped battery function, plug the adapter into MARS-3100R/S to charge the internal backup battery at least 24 hrs. Caution! If more than 3 minutes duration elapses between Step 4 and Step 5, removing and replacing the battery, any unsaved data will be lost.

  • Page 28: Figure 2.13 Auto Touchscreen Calibration

    2.5.2 AC Power The MARS-3100R/S can be powered exclusively with the supplied AC 19V adapter. It is not recommended to use any other adapter than the one supplied with the tablet Starting the tablet PC Press the power button once to turn on the tablet PC.

  • Page 29: Figure 2.14 Accessing The Configuration Utility

    Figure 2.14 Accessing the Configuration Utility In the Tools dialog, click on 4 Points Calibration to align the touchscreen. Figure 2.15 Calibrating the touchscreen Follow the onscreen instructions to calibrate the touchscreen. Figure 2.16 4 points calibration MARS-3100R/S User Manual...

  • Page 30: Figure 2.17 Draw Test

    Return to the Tools dialog; select Linearization for 9 points linearization, and fol- low the onscreen instructions; then, return to the Tools dialog again and try the Draw Test. Figure 2.17 Draw test MARS-3100R/S User Manual...

  • Page 31: Figure 2.18 Using The Pen

    Using the Pen The touchscreen pen is a tool supplied with the MARS-3100R/S. It is used exclu- sively as a control device for the touchscreen. It resembles a regular ballpoint pen. Instead of a regular onscreen cursor, the pen contacts the surface of the screen.

  • Page 32: Connecting Peripherals

    Connecting Peripherals The MARS-3100R/S supports several peripheral connections. 2.9.1 USB ports 2.9.2 COM ports The COM port of MARS-3100R/S is “COM3.” MARS-3100R/S User Manual Figure 2.19 USB port Figure 2.20 COM port...

  • Page 33: Figure 2.21 Audio Jacks (Red: Input And Green: Output)

    2.9.3 Audio jacks Figure 2.21 Audio Jacks (Red: input and Green: output) 2.9.4 VGA port Figure 2.22 VGA port MARS-3100R/S User Manual...

  • Page 34: Figure 2.23 Lan Port

    In this mode, although power consumption is very low, the battery may drain and cause data loss. If the MARS-3100R/S is stored for durations longer than a few hours or overnight, it is best simply to turn off the computer instead of using Suspend-to- RAM mode.

  • Page 35: Resuming

    2.11.2 Resuming When the system is in suspend mode, press the power button once, and the system will resume to normal operation again. Note! It may be necessary to log-on again after the system has resumed. MARS-3100R/S User Manual...

  • Page 37: Chapter 3 Advantech Central Manager

    Chapter Advantech Central Manager This chapter explains how to use the Advantech Central Manager program application. Sections include: ! Overview ! Display ! Hotkeys ! Power ! Image Version ! Audio ! Touch ! LAN ! Security...

  • Page 38: Figure 3.1 Central Manager Icons

    Overview The Advantech Central Manager utility is configures settings, operate devices and adjust the MARS-3100R/S. The Central Manager provides user-friendly functions. Display settings Screen resolutions Hotkey assignments Power management Audio & touchscreen controls LANs Network security The Central Manager utility is available from the taskbar in the bottom right corner of the Windows desktop.

  • Page 39: Figure 3.4 Vertical Display Mode

    Display 3.2.1 Rotation Users may change the orientation of the desktop display on MARS-3100R/S. In the Display menu, the Rotation control toggles horizontal (“landscape”) or vertical (“por- trait”) display modes. The orientation of the display switches relative to the horizontal and vertical axis of the tablet PC.

  • Page 40: Figure 3.5 Horizontal Display Mode

    R key, located on the upper right side of the bezel, second from the top. 3.2.3 Properties Click Properties menu. MARS-3100R/S User Manual to switch the display to the horizontal axis (land- Figure 3.5 Horizontal display mode to open the Windows Display Properties Figure 3.6 Display properties menu...

  • Page 41: Figure 3.7 Brightness Adjustment

    3.2.4 Brightness adjustments (MARS-3100R only) MARS-3100R has a brightness adjustment control feature. adjust the intensity of the display, use the pen to click right for brighter, or click left for darker. Figure 3.7 Brightness adjustment MARS-3100R/S User Manual...

  • Page 42: Figure 3.8 Three Hotkey Buttons

    Using Hotkey Buttons The MARS-3100R/S features a handy hotkey command control sys- tem. Three F hotkey buttons are available on the front bezel. These keys may be set to open software applications instantly. Figure 3.8 Three hotkey buttons Select the Hotkey menu to configure hotkey-activated software applications.

  • Page 43: Figure 3.10 Power Menu

    3.4.1 Power button settings The main power button, located on the top right side of the MARS-3100R/S, may be set to carry out four commands. The Power Button command on the Power menu supports four options.
  • Page 44 Pressing the Key button or the Ctl-Alt-Del key combo presents the Sign-on menu and the user must key-in log-on data. MARS-3100R/S User Manual...

  • Page 45: Figure 3.11 Advanced Power Settings

    3.4.2 Advanced Power settings The MARS-3100R/S supports a variety of precise power settings. Power Schemes Alarms Power Meter Advanced Hibernate Click Advanced on the main Power menu to open the Power Options Properties menu of the Central Manager. Figure 3.11 Advanced power settings 3.4.2.1...
  • Page 46 Selection defaults for this setting. Turns off monitor: After 15 minutes (Plugged in); After 1 minute (Batteries) Turns off hard disks: Never (Plugged in); After 3 minutes (Batteries) System Standby: After 20 minutes (Plugged in); After 2 minutes (Batteries) MARS-3100R/S User Manual...

  • Page 47: Figure 3.14 Low Battery Alarm Options

    Alarm action: The user may select the Alarm action check box to instruct the system what to do when the low battery alarm sounds, which is either Standby or Shut down. Figure 3.14 Low battery alarm options Figure 3.13 Power alarm options MARS-3100R/S User Manual...

  • Page 48: Figure 3.15 Run A Program Configuration Dialog Boxes

    Standby or Shut down. Figure 3.16 Critical battery alarm options Run a program: By selecting the checkbox, When the alarm occurs, run this pro- gram, users may choose to Configure program automatically. (See section 3.4.2.2.1 above.) MARS-3100R/S User Manual...

  • Page 49: Figure 3.18 Detailed Battery Information

    Battery # 1 to access precise data about the type and status of the battery currently active in the unit. Figure 3.18 Detailed battery information Figure 3.17 Power meter to open a new dialog box: Detailed information for MARS-3100R/S User Manual...

  • Page 50: Figure 3.19 Advanced Power-Saving

    Ask me what to do – Standby – Shut down (default setting) Sleep Button options: – No support "Sleep mode" (default setting) Note! Normally, the Power button setting is accessed through the main Power menu. (See section: 3.4.1, Power Button Settings.) MARS-3100R/S User Manual...

  • Page 51: Figure 3.20 Hibernate

    3.4.2.5.2 Disk space for hibernation This box displays the Free disk space presently available on the computer and the amount of minimum disk space required to activate the Hibernate function. Figure 3.20 Hibernate MARS-3100R/S User Manual...

  • Page 52: Figure 3.21 Image Version

    The Image version menu displays information about the status of the OS that is cur- rently installed on the MARS-3100R/S. Normally, the OS is Microsoft Windows XP Embedded Service Pack 2. The data displayed here also details the current version of BIOS installed in the system, and its build date.

  • Page 53: Figure 3.22 Main Audio Menu

    The Audio menu displays two slider controls to adjust the volume of the speaker and the microphone. To make basic adjustments, place the pen on the slider button and move it up or down. 3.6.1 Sounds and Audio Devices Properties The MARS-3100R/S supports a variety of precise audio settings. Audio devices Volume Sounds Voice...

  • Page 54: Figure 3.24 Volume And Advanced Buttons

    Click the Volume button to access the Volume Control sub-menu. Five settings may be adjusted for the sound playback device. The volume and balance of software and external devices is controlled with sliders using the pen. Figure 3.25 Playback volume control MARS-3100R/S User Manual Figure 3.23 Audio menu...

  • Page 55: Figure 3.27 Performance Properties

    Normally, it will not be necessary to adjust these features unless the system has trouble playing back audio. Click Restore defaults to reset the system defaults to maximum. Figure 3.27 Performance properties MARS-3100R/S User Manual...

  • Page 56: Figure 3.30 Advanced Controls For Microphone

    Microsoft GS Wavetable SW Synth. MIDI music playback also displays a volume control sub-menu that is identical to the Playback volume control; (See Figure 3.25) for fine-tuning MIDI devices. MARS-3100R/S User Manual Figure 3.28 Sound recording menu Figure 3.29 Recording controls...

  • Page 57: Figure 3.33 Speaker Volume

    Note! Clicking Advanced in Speaker set- tings on the main Volume menu opens the Advanced Audio Prop- erties sub-menu, as described in section 3.6.1.1.3, Advanced audio properties. (See MARS-3100R/S User Manual page 38 above.)

  • Page 58: Figure 3.34 Sounds Menu

    The Sounds menu also displays a scrolling list of all events to which sounds may be assigned. Use the pen to select Program events and assign a sound (wav) file to each event from selections on the Sounds drop-down list. MARS-3100R/S User Manual Figure 3.34 Sounds menu...

  • Page 59: Figure 3.36 Hardware Test For Microphone Level

    Follow the onscreen instructions to calibrate the microphone. Figure 3.36 Hardware test for microphone level Note! A microphone must be connected to the computer, or the internal micro- phone must be activated. (See Chapter 2.8, Connecting Peripherals.) Figure 3.35 Voice menu MARS-3100R/S User Manual...

  • Page 60: Figure 3.37 Hardware Menu

    The General menu displays details about the manufacturer, date and functional status of the selected item. Note! To access the Troubleshooting help from the Hardware menu, or any sub-menu, the MARS-3100R/S must be connected to the Internet. MARS-3100R/S User Manual Figure 3.37 Hardware menu Figure 3.38 General menu...

  • Page 61: Figure 3.39 Properties Menu

    The Driver menu displays a description of the manufacturer, date, version and signification of the selected device driver. The menu permits updates, rollbacks and uninstalling of drivers. Figure 3.40 Driver menu – Click Driver Details to view a full list of all active drivers. Figure 3.41 Driver details MARS-3100R/S User Manual...

  • Page 62: Figure 3.43 Touchscreen Calibration

    Click Calibration to activate the resistive touchscreen calibration tool. Follow the onscreen instructions to calibrate the touchscreen. Press the pen onto the middle of each X until it stops flashing and another one appears.l Figure 3.43 Touchscreen calibration MARS-3100R/S User Manual Figure 3.42 Touch menu...

  • Page 63: Figure 3.44 Digitizer Calibration Step 1

    Figure 3.44 Digitizer Calibration Step 1 Figure 3.45 Digitizer Calibration Step 2 Figure 3.46 Digitizer Calibration Step 3 Figure 3.47 Digitizer Calibration Step 4 MARS-3100R/S User Manual...

  • Page 64: Figure 3.49 Pen Tablet Properties Menu

    Control Utility for MARS-3100R Click Control Utility to open the Pen Tablet Properties tool to modify the sensitivity of the pen / digitizer settings, and to calibrate the pen for the MARS-3100R. Figure 3.49 Pen tablet properties menu MARS-3100R/S User Manual...

  • Page 65: Figure 3.50 Buttons Menu

    3.7.2 Mouse The MARS-3100R/S supports a variety of precise Mouse settings. Buttons Pointers Pointer Options Hardware Click Mouse Properties to access the sub-menus. 3.7.2.1 Buttons The first tab on Mouse Properties is the Buttons menu. Three Button fields are displayed on the menu.

  • Page 66: Figure 3.52 Pointer Options Menu

    Move the slider to control the distance that the cursor travels relative to the amount of mouse movement required. To enhance the sensitivity of the pointer for precise work, select the Enhance pointer precision check box. MARS-3100R/S User Manual Figure 3.51 Pointers menu Figure 3.52 Pointer options menu...

  • Page 67: Figure 3.54 General Usb Properties

    Click Properties to access sub-menus for adjustment of the mouse. Note! To access the Troubleshooting help from the Hardware menu, or any of the sub-menus, the MARS-3100R/S must be connected to the Inter- net. 3.7.2.4.1 General USB properties The General sub-menu describes the type of touchscreen controller hardware that is installed on the system.

  • Page 68: Figure 3.55 Usb Driver Properties

    Select the second check box to use the mouse to turn the computer on, and bring it out of standby mode. Figure 3.56 USB power management MARS-3100R/S User Manual Figure 3.55 USB driver properties...

  • Page 69: Figure 3.57 Network Connections

    The LAN menu displays the status of the Ethernet hardware device installed on the MARS-3100R/S, including its name and connection addresses. The status of the Ethernet or Wireless will turn “ON” once the MARS-3100 is already connected. An “OFF” message indicates that the computer is not connected.

  • Page 70: Figure 3.59 Security Center

    Click Windows Security Center to set the degree of network security. The Center offers precise control over firewalls and antivirus applications. If the computer is con- nected to a network, it may receive automatic updates and access antivirus software. MARS-3100R/S User Manual Figure 3.58 Security menu Figure 3.59 Security center...

  • Page 71: Chapter 4 Maintenance And Troubleshooting

    Chapter Maintenance and Troubleshooting This chapter explains how to care for and maintain the Tablet PC along with a troubleshooting FAQ. Sections include: ! Care, Storage and Cleaning ! Replacing Components ! Troubleshooting ! OS Maintenance and Re-Instal- lation...

  • Page 72: Care, Storage And Cleaning

    4.1.1 Protect the computer from damage The MARS-3100R/S is built to withstand extreme conditions of high and low temper- ature and physical shock when dropped from any side. However, the utmost care should be exercised to ensure that the computer is operated within its specific opera- tional limits.

  • Page 73: Cleaning The Computer

    Note! Do not use alcohol or abrasive cleansers to clean either the touch- screen or the computer. Use only mild, detergent-based (household) degreasers to remove oil or tar. MARS-3100R/S User Manual...

  • Page 74: Figure 4.1 Removing The Battery Pack

    4.2.1 Battery Turn off the MARS-3100R/S Disconnect any peripheral devices from the MARS-3100R/S. Unfasten the two large flathead screws and remove the old battery. Figure 4.1 Removing the battery pack Insert the new battery pack. Fasten the two flathead battery cover screws.

  • Page 75: Figure 4.3 Hard Disk Drive

    The hard disk drive (or optional CF card) is accessed behind the port on the backside of the computer. Turn off the MARS-3100R/S. Remove the DC adapter and Battery pack from MARS-3100R/S. Disconnect any peripheral devices from the MARS-3100R/S. Unfasten the four small screws and remove the cover.

  • Page 76: Figure 4.7 Unplugging The Cable Connector

    Do not grasp the HD with the thumb in the middle of the housing. Do not twist or bend either the HD or the CF card during removal. Grasp the cable connector firmly. Unplug the connector, pulling it straight out. Figure 4.7 Unplugging the cable connector MARS-3100R/S User Manual...

  • Page 77: Figure 4.8 Removing The Cf Card

    Remove the CF card from the slot. Figure 4.8 Removing the CF card MARS-3100R/S User Manual...

  • Page 78: Troubleshooting

    Check to see a new battery is inserted and connected. Remove the battery and the AC adapter and reinstall both. Under conditions of extremely high or low temperature, it is possible that the computer may not function. Use the MARS-3100R/S only within its recom- mended operational parameters. 4.3.2...

  • Page 79: The Amber Battery Status Led Is Always On

    Charge the battery; replace the battery if it is spent. 4.3.10 The amber battery status LED is blinking Battery is critically low. Charge the battery; replace the battery if it is spent. 4.3.11 The amber battery status LED is blinking quickly Battery error. Replace the battery. MARS-3100R/S User Manual...

  • Page 80: Figure 4.9 Welcome To Windows Xp

    Connect one CD/DVD-ROM drive to the MARS-3100R. Note! Recommended drive: USB external CD/DVD-ROM. Insert the Recovery Media CD into the CD/DVD-ROM. The CD/DVD-ROM autoplays the CD and pops up this window: Figure 4.9 Welcome to Windows XP MARS-3100R/S User Manual...

  • Page 81: Figure 4.11 Install Windows Xp

    “Window”. So, if you come across any similar prob- lems in using the Digitizer Touch, please follow the instructions below. Figure 4.10 XP setup icon Figure 4.11 Install Windows XP MARS-3100R/S User Manual...
  • Page 82 Approaching the “X” symbol is the same as usual. Keep the pointer completely inside the “X” symbol. Press the icon a little harder until the icon becomes darker. Then you can close the window.

  • Page 83: Appendix Agprs Setting

    Appendix GPRS Setting This chapter details instructions about how to set up the GPRS soft- ware connection for the MARS- 3100R/S.

  • Page 84: Setting Up The Modem

    Setting Up the Modem Select and enter Phone and Modem Options in Control Panel. Select the country/region. MARS-3100R/S User Manual...
  • Page 85 Enter the local Area Code and click OK. It is sufficient to leave the other column blank. The system adds a new location named My Location. Select the Modem page and click Properties. MARS-3100R/S User Manual...
  • Page 86 Click the Diagnostics page. Click Query to check the communication with the modem device. Information from the device is displayed if communication is successful. MARS-3100R/S User Manual...
  • Page 87 PDP type = “IP” and the “internet” represents the Access-point Name (APN) for GPRS service in Taiwan. Since these data vary from one region and country to the next, it is important to verify the local APN with the local ISP supplier. MARS-3100R/S User Manual...

  • Page 88: Setting Up An Internet Connection

    Setting Up an Internet Connection Select and enter Network Connections in Control Panel. Select the link, Create a new connection. MARS-3100R/S User Manual...
  • Page 89 Click Next to continue. Select Connect to the internet when the table below appears. Click Next to continue. Select Set up my connection manually and click Next to continue. MARS-3100R/S User Manual...
  • Page 90 Select Connect using a dial-up modem and click Next to continue. Enter the local network ISP name; for example, “TEST.” Enter the phone number: *99***<CID># and click Next to continue. Note! If the CID is “1” in your region, then enter: *99***1# MARS-3100R/S User Manual...
  • Page 91 Ignore the user name request and click Next to continue. Finish the set up process. MARS-3100R/S User Manual...

  • Page 92: Connect To The Internet By Gprs

    Connect to the Internet by GPRS Select and enter Network Connections in Control Panel. The ISP name created before appears (for example: TEST), right click and select Properties. MARS-3100R/S User Manual...
  • Page 93 Click Configure. Select 115200 for maximum speed, click OK twice and return to the desktop. Double click the connection (for example: TEST) MARS-3100R/S User Manual...
  • Page 94 Click Dial to access the internet via GPRS. Connection successful. MARS-3100R/S User Manual...

  • Page 95: Index

    INDEX Numerics 5-way navigation button 11 About this Manual 2 AC adapter 14 Accessories 6 Alarms 33 Ask me what to do 30 Audio Advanced audio properties sub-menu 41 Performance 41 Speakers 41 Devices 40 Hardware menu 46 Properties 46 Jacks 19 Menu 39 MIDI music playback 42...
  • Page 96 Battery status 9 HDD status 10 Power ON/OFF 9 Wireless LAN ON/OFF 10 LEDs 9 Maintenance Cleaning 59 Connections 58 Storage 58 Thermal stress 58 Touchscreen 58 MIDI music playback 42 Modem Setting up GPRS 70 Mouse Buttons 51 General USB properties 53 Hardware 53 Pointer Options 52 Pointers 52...
  • Page 97 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher.
