Tablet PC
AIM-77S Series
Startup Manual
AIM-77S Appearance
Up: AIM-77S (MSR SKU)
Left: Front View
For more information on this and other
Advantech products, please visit our website
at:
http://www.advantech.com
For technical support and service, please visit
our support website at:
http://support.advantech.com
This manual is for AIM-77S Series
Down: AIM-77S (non-MSR SKU)
Right: Rear View
First Edition
March 2025
Description of Parts
A: Power Indicator & Hall Sensor
B: Ambient Light Sensor
C: 5MP Front Camera (FF)
D: Barcode Scanner (optional)
E: microSD Slot
F: USB Type C (USB3.0 & 45W PD3.0)
G: Audio Combo Jack (CTIA)
H: Microphone
I: Barcode Trigger Button
J: 8MP Rear Camera (AF)
K: Power Button
L: Volume Key (up & down)
M: NFC (optional)
N: MSR (optional)
O: Pogo pin for Peripherals
P: Speaker
Advertisement
Table of Contents
Related Manuals for Advantech AIM-77S Series
Summary of Contents for Advantech AIM-77S Series
- Page 1 I: Barcode Trigger Button J: 8MP Rear Camera (AF) K: Power Button L: Volume Key (up & down) This manual is for AIM-77S Series M: NFC (optional) N: MSR (optional) First Edition O: Pogo pin for Peripherals March 2025...
-
Page 2: Easy Setup
Environment: ◼ Operating Temperature: -0°C ~ +40°C The shipping image can be updated by OTA via ◼ Humidity: 90% at 40°C (non-condensing) DeviceOn (Advantech MDM tool) or by USB drive ◼ Storage/Transportation Temperature: or by anther PC. -10°C ~ +60°C. -
Page 3: Safety Instructions
L'AIM-77S est conçu avec une batterie intégrée non l'appareil ne doit être effectuée que par un personnel remplaçable. Ne remplacez pas la batterie vous-même. qualifié. Advantech recommande de contacter le service Veuillez contacter un technicien qualifié ou votre après-vente Advantech et de confier toutes les revendeur pour obtenir de l'aide. - Page 4 Repair of the device may only be carried by trained service personnel. Advantech recommends that a service contact be obtained with Advantech service and that all repairs also be carried out by them; otherwise the correct functioning of the device may be compromised.
-
Page 5: Declaration Of Conformity
This equipment has been tested and found to comply available at the following internet address: with the limits for a Class B digital device, pursuant to https://www.advantech.com part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful The device is restricted to indoor use only when interference in a residential installation. - Page 6 End-users and installers must be provided with antenna permissible gain and required installation instructions and transmitter operating antenna impedance are strictly prohibited for use with conditions for satisfying RF exposure compliance. this device. For product available in the USA/Canada market, only channel 1~11 can be operated.
-
Page 7: Additional Information And Assistance
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei, Taiwan 114, R.O.C. TEL: (02) 7732-3399 Distributed in Europe by: Advantech Europe GmbH Kolberger Straß e 7 D-40599 Düsseldorf, Germany Tel: 49-211-97477350 Fax: 49-211-97477300 Visit the Advantech websites at www.advantech.com or www.advantech.com.tw... - Page 8 平板電腦 AIM-77S 系列 快速入門手冊 AIM-77S 外觀 外觀描述 AIM-77S (MSR) AIM-77S (non-MSR) 左邊：前視圖 右邊：後視圖 如需瞭解有關本產品及研華其他產品的詳細資訊 ， 請瀏 覽我們的網站： http://www.advantech.com/ 如需技術服務與支援，請瀏覽我們的技術支援網站： A: 電源指示燈 & 霍爾感測器 http://support.advantech.com B: 環境光感測器 C: 五百萬畫素固定對焦前鏡頭 本手冊適用於 AIM-77S 系列。 D: 條碼讀取器(BCR) (選配) E: microSD 卡槽 第一版 F: USB Type C (USB3.0 & 45W PD3.0) 2025 年...
- Page 9 接通電源 號或使用者均不得擅自變更頻率、加大功率或變更原設計 之特性及功能。 AIM-77S(本產品)電源 供電使 用 FSP(全漢 )型號: 低功率射頻器材之使用不得影響飛航安全及干擾合法通 FSP045-A2BR3 的交換式電源供應器，輸入額定為 信；經發現有干擾現象時，應立即停用，並改善至無干擾 15 Vdc / 3 A (Type C)。如需進一步協助，請聯絡 時方得繼續使用。前述合法通信，指依電信管理法規定作 Advantech 取得更多資訊。 業之無線電通信。低功率射頻器材須忍受合法通信或工 本產品採用運輸節電機制 (shipping mode)，以保護 業、科學及醫療用電波輻射性電機設備之干擾。」 電池並減少運送過程電力耗用，因此，在首次使用前， 請先對主機充電，將附件 USB Type-C 電源供應器 減少電磁波影響，請妥適使用 連上，以便解鎖 AIM-77S 的運輸節電機制。 應避免影響附近雷達系統之操作。 長按電源開關 (外觀描述的”K”位置) 2~3 秒鐘可以...
- Page 10 AIM-77S 技術規格 BSMI 系列型號 限用物質含有情況標示聲明...
