Getting started

Wall mounting

The telephone base comes with the bracket mounted for tabletop use. If wall-
mounting is desired, follow the directions below.
1. To remove the bracket, hold the telephone
base in both hands, press the two bracket tabs
and lift the bracket away from slots
3. To attach the bracket for wall mounting,
insert the tabs of the bracket into the slots
and on the telephone base, then
press the other bracket tabs into slots
and as shown on the right.
4. Plug the power adapter into an electrical
outlet not controlled by a wall switch. Plug
the telephone line cord into a telephone
wall jack. To mount the telephone on the
wall, position the mounting holes
over the wall outlet mounting pegs.
Press and slide the bracket down firmly
so the telephone is held securely on the
telephone outlet mounting pegs.
NOTE: To change back to tabletop mounting, remove the telephone
base from the wall and remove the bracket from the telephone base (see step
1). Unplug the cords from the wall jacks. Insert the bracket tabs into the slots
and on the telephone base, then press the other bracket tabs into the
slots and . Connect the telephone line cord and power adapter (see page
7).
2. Connect the telephone line cord and power
adapter to the jacks on the bottom of the tel-
and . ephone base. Wrap the cords as shown. Put
the telephone line into the bracket.
and
Telephone outlet mounting pegs
