Summary of Contents for Lester 26610
- Page 1 USER’S MANUAL Model 26610 Important Safety, Installation, Operation, and Maintenance Instructions www.LesterElectrical.com...
-
Page 2: Table Of Contents
11. TROUBLESHOOTING AND SERVICE ................15 11.1 RE-STARTING A CHARGE CYCLE WHILE TROUBLESHOOTING ..... 15 12. SERVICE PARTS ......................16 13. WIRING DIAGRAM ......................17 14. SPECIFICATIONS......................17 LIMITED WARRANTY ......................18 User’s Manual Links Series Model 26610 2 of 20... -
Page 3: Important Safety Instructions
CONDITION. DO NOT USE CONNECTORS THAT ARE CRACKED, CORRODED OR DO NOT MAKE ADEQUATE ELECTRICAL CONTACT. USE OF A DAMAGED OR DEFECTIVE CONNECTOR MAY RESULT IN A RISK OF OVERHEATING OR ELECTRIC SHOCK. User’s Manual Links Series Model 26610 3 of 20... - Page 4 CHARGER MAY RESULT IN AN EXPLOSION, ELECTRIC SHOCK, OR FIRE. CAUTION: MAKE SURE THE BATTERY SYSTEM HAS THE PROPERLY RATED VOLTAGE, AMP-HOURS, AND TYPE (“WET”) FOR THIS CHARGING SYSTEM. SAVE THESE INSTRUCTIONS User’s Manual Links Series Model 26610 4 of 20...
-
Page 5: Notice
Club Car® and PowerDrive® are registered trademarks of Club Car, Inc. 1. SYSTEM OVERVIEW The Lester Electrical Links Series Model 26610 battery charger functions as an integral part of Club Car® Excel, IQ, PowerDrive® and PowerDrive® Plus electrical systems. Because the charger is controlled by the vehicle onboard computer, it will work with only Excel System, IQ System, PowerDrive®, and PowerDrive®... -
Page 6: Battery Warning Light
FUELS, GRAIN DUST, SOLVENTS, THINNERS, OR OTHER FLAMMABLES. WARNING: REPLACE WORN, DAMAGED, OR CUT ELECTRICAL CORDS AND PLUGS IMMEDIATELY. WARNING: KEEP DRY; DO NOT EXPOSE TO RAIN OR SPRAY. FOR STORAGE, KEEP CHARGER IN A BUILDING. User’s Manual Links Series Model 26610 6 of 20... - Page 7 • INSTALL SURGE ARRESTORS ON INCOMING AC POWER LINES. SURGE ARRESTORS WILL HELP PROTECT ELECTRICAL COMPONENTS IN THE CHARGER AND ON THE VEHICLE FROM ALL BUT DIRECT OR CLOSE LIGHTENING STRIKES. User’s Manual Links Series Model 26610 7 of 20...
-
Page 8: Ac Input
SCREW OF THE OUTLET PLATE IS GROUNDED. Figure 7-1: Grounding Methods (NOTE: Use of an adapter as shown in Figures B and C is NOT permitted in Canada) The charger includes an AC input circuit breaker. User’s Manual Links Series Model 26610 8 of 20... -
Page 9: Proper Care Of Deep Cycle Motive Power Patteries
7. Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a battery. A battery can produce a short-circuit current that is high enough to cause a severe burn. 8. NEVER charge a frozen battery. User’s Manual Links Series Model 26610 9 of 20... -
Page 10: Charger Operation
AND PULL THE PLUG STRAIGHT OUT OF THE RECEPTACLE. • DO NOT CONNECT A CHARGER TO THE RECEPTACLE IF THE CHARGER CORD, PLUG, OR THE VEHICLE RECEPTACLE IS BROKEN, DAMAGED IN ANY MANNER, OR DOES NOT MAKE A GOOD User’s Manual Links Series Model 26610 10 of 20... - Page 11 Vehicles should be restricted to 40 to 50 energy units of discharge (or 36 holes of golf) between charges until the batteries have been properly seasoned (20 to 50 charge cycles). For maximum User’s Manual Links Series Model 26610 11 of 20...
-
Page 12: Charger Plug And Receptacle
See following NOTE. NOTE: If the warning tag has been damaged or removed from the DC cord, have it replaced immediately. User’s Manual Links Series Model 26610 12 of 20... -
Page 13: User Interface
The user interface (Figure 9.2-1) includes an ammeter for monitoring the DC output current of the charger. The user interface also includes an AC input circuit breaker. Figure 9.2-1: Links Series Model 26610 User Interface User’s Manual Links Series Model 26610... -
Page 14: Maintenance
Periodic cleaning and watering of non-sealed batteries is very important. Logging the water usage of non- sealed batteries is useful. As a battery ages, it will use more water. User’s Manual Links Series Model 26610 14 of 20... -
Page 15: Troubleshooting And Service
3 seconds before the charge cycle continues. If the batteries are close to being fully charged, the charge cycle will begin and the charge current will begin to taper within a few minutes. User’s Manual Links Series Model 26610 15 of 20... -
Page 16: Service Parts
12. SERVICE PARTS Figure 12-1: Links Series Model 26610 Service ISO View SERVICE PARTS LIST Service Part Description Fuse Assembly 30784S Relay Board Assembly 26150S Kit, Diode Assemblies 38463S AC Circuit Breaker 31847S Ammeter 31158S AC Cordset Kit 21307-06S DC Cordset Kit 36413S User’s Manual... -
Page 17: Wiring Diagram
AC cord length (182.9 cm) 104 in. DC cord length (264 cm) 24.25 lb. Weight (11 kg) MOUNTING CONFIGURATION Set on shelf, wall mount with keyhole, Mounting or hang securely from ceiling. User’s Manual Links Series Model 26610 17 of 20... -
Page 18: Limited Warranty
Lester Electrical warrants each new Lester Battery Charger for defects in material and workmanship for a period of two (2) years from the date of manufacture of the complete unit. Repairs can be made at the Lester factory. To do so, first obtain a "Return Material Authorization"... - Page 19 NOTES User’s Manual Links Series Model 26610 19 of 20...
- Page 20 Represented By: 38459B User’s Manual Links Series Model 26610 20 of 20...
