Lester 19300 Owner's Manual

AC Input:
DC Output:
Connections:
Dimensions:
Mounting:
Weight:
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of this charger, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS.
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, PERSONAL INJURY OR PROPERTY DAMAGE CAN OCCUR.
INTRODUCTION
This battery charger is designed to recharge deep-
cycle, wet lead-acid batteries.
transformer is used to provide a highly reliable, AC
line voltage compensating unit with a minimum of
moving parts, designed for long, trouble-free service.
An electronic charge controller turns the charger on
and off automatically. This controller determines full
charge of the batteries by measuring the rate at
which the battery voltage increases.
battery is fully charged, the charger turns off.
INITIAL INSTALLATION
The AC line to which the charger is to be connected
must be capable of supplying 10 amperes to this
charger.
www.lesterelectrical.com
OWNERS MANUAL
BATTERY CHARGER
MODEL 19300
108-125 Volts AC, 60 Hertz, single-phase, 10.5 amps
36 Volts DC, 21 amps tapering to 6 @ 45 VDC
9 1/4 ft. DC cord with Power Wise plug, Option -98 (602718)
17 ft. DC cord with Power Wise plug, Option -18 (602719)
9 ¼ ft. DC cord with Anderson SB 50 gray connector, Option -03 (602715)
6 ft. DC cord with ring terminal & QD ignition enable, Option -23 (602714)
6 ft. min. / 7 ¾ ft. max. AC cord with grounded 3-prong plug
8-15/16H X 7-13/16W X 10-5/8D
Set on shelf, wall mount with keyholes, or hang from ceiling securely
31 lbs.
DO NOT DISCARD THIS MANUAL AFTER READING.
A ferroresonant
When the
Specifications
CAUTION: TO REDUCE THE RISK OF FIRE,
USE THIS CHARGER ONLY ON CIRCUITS
PROVIDED WITH A MAXIMUM OF 20 AMPERE
BRANCH
BREAKER OR FUSE), IN ACCORDANCE WITH
THE NATIONAL ELECTRICAL CODE, ANSI/NFPA
70, AND ALL LOCAL CODES AND ORDINANCES.
The use of an extension cord with the charger
should be avoided.
extension cord could result in a risk of a fire or
electric shock. If an extension cord must be used,
use a three-conductor, No. 14 AWG cord with
ground, properly wired, in good electrical condition
and keep it as short as possible. Make sure that the
pins on the plug of the extension cord are the same
number, size, and shape as that of the plug on the
battery charger. Locate all cords so that they will not
be stepped on, tripped over, or otherwise subjected
to damage or stress.
1
*34943*
CIRCUIT PROTECTION
The use of an improper
IT MEANS:
(CIRCUIT
34943F
