TROUBLESHOOTING, REPAIR, AND REPLACEMENT
GUIDE FOR MODEL #19300 BATTERY CHARGER
PLEASE SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS. IT MEANS:
BECOME ALERT-YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW
THESE SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN
OCCUR.

TABLE OF CONTENTS

INTRODUCTION ....................................................................................................................... 2
PROPER CARE OF MOTIVE POWER BATTERIES................................................................. 2
TROUBLESHOOTING GUIDE .................................................................................................. 3
1.
CHARGER DOES NOT TURN ON............................................................................ 4
2.
CHARGER FUSE BLOWS ........................................................................................ 5
3.
AMMETER READS 25 AMPS FOR MORE THAN 30 MINUTES .............................. 6
4.
CHARGER OUTPUT IS LOW ................................................................................... 6
5.
CHARGER TURN-OFF MALFUNCTIONS ................................................................ 6
6.
AC LINE FUSE OR CIRCUIT BREAKER BLOWS .................................................... 8
COMPONENT TEST PROCEDURES ....................................................................................... 9
7.
ELECTRONIC CHARGE CONTROLLER TESTING ................................................. 9
8.
TRANSFORMER TESTING .................................................................................... 12
9.
DIODE ASSEMBLY TESTING ................................................................................ 14
10.
CAPACITOR TESTING ........................................................................................... 17
11.
AC INPUT CIRCUIT TESTING................................................................................ 19
12.
DC OUTPUT CIRCUIT TESTING............................................................................ 20
COMPONENT REPLACEMENT PROCEDURES ................................................................... 21
13.
ELECTRONIC CHARGE CONTROLLER REPLACEMENT .................................... 21
14.
DIODE ASSEMBLY REPLACEMENT ..................................................................... 23
15.
CAPACITOR REPLACEMENT................................................................................ 25
16.
AC INPUT AND DC OUTPUT CORD REPLACEMENT .......................................... 26
17.
FUSE ASSEMBLY REPLACEMENT....................................................................... 27
CHARGER WIRING DIAGRAM............................................................................................... 28
CHARGER COMPONENTS EXPLODED VIEW ..................................................................... 29
SERVICE PARTS LIST ........................................................................................................... 29
www.lesterelectrical.com
DO NOT DISCARD THIS MANUAL AFTER READING.
1
*35827*
35827_A
