Lester 16360 Safety And Operating Instructions Manual

36 VOLT FULLY AUTOMATIC
DUAL MODE BATTERY CHARGER
MODEL 16360
AC Supply:
DC Output:
Battery Capacity:
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS.
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN OCCUR.

INTRODUCTION

This battery charger provides superior battery
performance and life, with low electrical power
consumption. The solid state design provides a
highly reliable, self-regulating
minimum of moving parts, designed for long, trouble-
free service. The Dual-Mode design allows the
charger to be used on either liquid electrolyte or
sealed "maintenance free" lead acid batteries.
Simply set the battery mode switch to the type of
batteries being charged and the charger output is
automatically adjusted to the proper level. When the
batteries have reached their maximum state of
charge, the solid state control turns the charger off.
www.lesterelectrical.com
WORLD CHARGER
100-125 or 200-250 volts, 50 or 60 Hertz, single-phase
36 volts, 20 amps
Use only on 36 volt, 18 cell, 180 to 305 ampere-hour (20 hr. rate) liquid electrolyte or
sealed "maintenance free" lead acid batteries
DO NOT DISCARD THIS MANUAL AFTER READING.
charger with
TYPE 36EL20-8ET

Specifications

INITIAL INSTALLATION

This charger is equipped with an input AC voltage
select switch located on the front of the charger.
Properly setting the switch allows the charger to
a operate from either 100 to 125 volt or 200 to 250 volt
single phase, 50 or 60 Hertz outlets. Set the input
AC voltage select switch to 115 for a measured input
voltage of 100 to 125 VAC or 230 for a measured
input voltage of 200 to 250 VAC.
The charger battery mode switch must be set
correctly to charge either wet, or sealed, including
gel cell, lead acid batteries. Sliding the switch to gel,
sealed or maintenance free charges the battery to a
maximum of 2.38 volts per cell. The liquid or wet
setting allows the battery to charge to 2.5 to 2.6 volts
per cell.
1
∗01413∗
IT MEANS:
01413H
