* NOTE – The Total and Grand Total values are available in 3 formats: 64-bit
in a single register, 64-bit in four consecutive 16-bit registers and 32-bit in
two consecutive 16-bit registers. The 64-bit format is recommended for
greater precision, especially with values greater than 7-digits.
HIT-4U
Description
Request Event
Log Download
Pointer
Fault History
Active Faults
Request Rate
Request Current
Total
Request Grand
Total
Request Current
Total
Request Grand
Total
Modbus Communications
Data Access
Type
FP32 R/W
U32 RO
U32 RO
FP32 RO
FP64 RO
FP64 RO
FP32 RO
FP32 RO
Notes
-1 (cleared logs) –
344 (To increment
by one, use function
code 5)
Fault has occurred
since last power on.
Each bit represents a
specific fault
defined below.
Fault is currently
active. Each bit
represents a specific
fault defined below.
Rate stored in two
16-bit registers
Current Total stored
in four 16-bit
registers
Total is reset by
sending a read
request to register 9.
Grand Total stored
in four 16-bit
registers
Current Total stored
in two 16-bit
registers
Total is reset by
sending a read
request to register 9.
Grand Total stored
in two 16-bit
registers
