Modbus Communications
Register
(Decimal)
2059
2061
2063
2065
2067
2069
2071
2073
2075
2077
2079
2081
2083
2085
2087
2089
4000
4001
4003
4005
4007
4009
4011
4012
4013
HP-327
Description
Frequency 13
Frequency 14
Frequency 15
Frequency 16
Frequency 17
Frequency 18
Frequency 19
Frequency 20
K-Factor 13
K-Factor 14
K-Factor 15
K-Factor 16
K-Factor 17
K-Factor 18
K-Factor 19
K-Factor 20
Pulse Function
Pulse Width
(mS)
Pulse Scale
Analog Out
Function
Analog Out Low
Analog Out
High
Alarm Function
Total Alarm Set
Point
Rate Alarm Low
Set Point
38
Data Access
Type
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
FP32 R/W
U16 R/W
U16 R/W
U16 R/W
U16 R/W
FP32 R/W
FP32 R/W
U16 R/W
FP64 R/W
FP32 R/W
Notes
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-5000.000
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0.001-9999999
0=off, 1=on, 2=test
4-300mS
0=0.01, 1=0.1, 2=1,
3=10, 4=100
= off, 1 0 = rate,
2=4mA, 3=12mA,
4=20mA
0.000-999998
0.001-999999
0=off, 1=rate lo,
2=rate hi 3=rat lohi,
4=total, 5=test
0.001-99999999
0.001- Max limited
by rate decimal
point selection:
999.999, 9999.99,
99999.9, 99999
HIT-4U
